Shop JAN FAN

MountedFan, Silver, 20inDia, Steel, 3Blade

  • Mfr # JF-AKF20-DCS-Y

  • Zoro # G722587459

product price:
$
756.99
/ea
Free Shipping & Returns

Key Features

Features
Modular Design for Part Interchangeability, Positive Locking Guard with Quick-Release for Safe Access, Safety Cable for Over-Head Mounted Fans, Spring-Type Steel Blades with Front Hub
Air Velocity @ 40 Ft.
150 fpm
Voltage
115 V
Shaft Dia.
1/2 in
Air Velocity @ 80 Ft.
100 fpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
JF-AKF20-DCS-Y
Zoro #
G722587459
UPC #
-
Country of Origin
China

Dimensions

Shaft Dia.
1/2 in
Height Adjustment
78.3"
Depth
22 in
Blade Diameter
20 in
Fan Cord Length
18 ft
Height
24 5/8 in
Width
24 5/8 in

Details

Features
Modular Design for Part Interchangeability, Positive Locking Guard with Quick-Release for Safe Access, Safety Cable for Over-Head Mounted Fans, Spring-Type Steel Blades with Front Hub
Air Velocity @ 40 Ft.
150 fpm
Voltage
115 V
Air Velocity @ 80 Ft.
100 fpm
Number of Conductors
0
Blade Material
Steel
Mounting Surface
C-Channel, I-Beam
Motor Insulation
B
For Location
Garage, Fitness Center, Greenhouse, Manufacturing Plant, Warehouse
Airflow
2,818 cfm
Motor HP
1/4 hp
Amps
2.4/1.2 A
Max. Ambient Temp.
104 Degrees F
Sound Level
60.2 dB
Number of Blades
3
Watts
200/300 W
Air Velocity @ 20 Ft.
175 fpm
Hz
60/50 Hz
Air Velocity @ 10 Ft.
175 fpm
Assembly Required
Yes
Head Tilt Adjustment
180 Degrees
Item
Mounted Fan
RPM
900 RPM, 1,100 RPM
Environmental Applications
Agricultural, Commercial, Industrial
Wire Guard Finish
Powder Coated
NEMA Plug Configuration
5-15P
Drive Type
Direct Drive
Fan Power Source
Hardwired
Thermal Protection
Yes
Color
Yellow
Includes
Drop Cord Switch
Air Velocity @ 60 Ft.
100 fpm
Motor Enclosure
Totally Enclosed Non-Ventilated
Mount Type
Adapter Kit
Guard Material
Steel
Number of Speeds
2
Standards
ETL

Description

Mounted Fan, Non-Oscillating, Voltage 115 V, Air Velocity @ 20 Ft. 175 fpm, Motor HP 1/4 hp, Fan Mounting Location Ceiling, Floor, Wall, Sound Level 60.2 dB, Max. Ambient Temp. 104 Degrees F, Hz 60/50 Hz, Watts 200/300 W, Drive Type Direct Drive, Height 24 5/8 in, Width 24 5/8 in

Restrictions

This item has been restricted from sale in the following states: AK, HI
