Shop JOHNSON CONTROLS

Electric Actuator, On/Off, Floating, 24V

  • Mfr # M9104-IGA-2S

  • Zoro # G6867061

product price:
$
131.68
/ea
Free Shipping & Returns

Key Features

Mounting Type
Direct Mount
Spring Return
Non-Spring Return
Signal Type
Floating Point with Timeout, On/Off
Torque
35 in-lb
Voltage
24V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
M9104-IGA-2S
Zoro #
G6867061
UPC #
-
Country of Origin
Mexico

Dimensions

Height
5 5/32 in
Depth
2 1/4 in
Width
2 13/16 in
For Shaft Diameter
1/2 in
For Shaft Width
3/8 in
Overall Depth
2 1/4 in
For Shaft Height
3/8 in
Overall Width
2 7/8 in
Overall Height
5 1/8 in

Details

Mounting Type
Direct Mount
Spring Return
Non-Spring Return
Signal Type
Floating Point with Timeout, On/Off
Torque
35 in-lb
Voltage
24V AC
Type
Non-Spring Return
Power Consumption
3 VA
Timing
60 sec
Electrical Connections
Cable
Replaces Honeywell Motors
Mfr. No. ML6161B2024
Motor Direction
CW or CCW
Stroke Deg.
90
Item
Actuator
For Use With
Dampers and Valves
Includes
Anti-Rotation Bracket
Shaft Type
Self-Centering Clamping
Ambient Temp. Range
-4 Degrees to 140 Degrees F
Electrical Connection Type
Hardwired
Number of Auxiliary Switches
0
Input Voltage
24V AC
Product Type
Actuator
Minimum Operating Temperature
-4 Degrees F
For Shaft Shape
Round, Square
Time to Close
30 sec
Rated Torque
35 in-lb
For Use With Building Automation Systems
Building Automation System Compatible
Maximum Operating Temperature
140 Degrees F
Valve Application
Damper
Shaft Rotation
CW/CCW
Stroke Degree
93 Degrees
IP Rating
IP42
Standards
C-Tick Mark Australia, CE Certified, CSA Certified C22.2 No. 139, EMC Directive 2004/108/EC, Guide No. XAPX for USA and Canada, NZ Emissions Compliant, UL Listed 60730-1, UL Listed E4436
Plenum Rating
Plenum Rated
NEMA Rating
2
Application
Dampers, Zone Valves, VAV Boxes

Description

Actuator, Valve Application Damper, Signal Type Floating Point with Timeout, On/Off, Rated Torque 35 in-lb, Input Voltage 24V AC, Electrical Connection Type Hardwired, For Use With Building Automation Systems Building Automation System Compatible, NEMA Rating 2, IP Rating IP42, Spring Return Non-Spring Return, Time to Close 30 sec, Shaft Type Self-Centering Clamping, Shaft Rotation CW/CCW, Stroke Degree 93 Degrees , Mounting Type Direct Mount, Maximum Operating Temperature 140 Degrees F
