  11. Humidity Sensor, Duct, Tan
Johnson Controls Humidity Sensor, Duct, Tan HE-69S30NP-0 - main

Humidity Sensor, Duct, Tan

  • Mfr # HE-69S30NP-0

  • Zoro # G4315805

product price: $387.99
/ea
Free Shipping & Returns

Key Features

Material
Plastic
Includes
Test and Calibration Equipment Certificate of Calibration Conformance
Color
Tan
Voltage
14 V DC, 20 V AC, 30 V AC, 30 V DC
Operating Temp. Range (F)
-40 to 150
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HE-69S30NP-0
Zoro #
G4315805
UPC #
-
Country of Origin
Mexico

Dimensions

Height (In.)
2 in
Depth (In.)
1 1/2 in
Width (In.)
1 1/2 in
Sensor Diameter
1 mm
Overall Width
3 1/4 in
Overall Height
3 1/4 in
Overall Depth
3 5/16 in
Cable Length
10 ft
Probe Length
6 in
Overall Length
8 1/4 in
Manufacturers Warranty Length
3 yr
Probe Diameter
1 in

Details

Item
Humidity Sensor
Material
Plastic
Includes
Test and Calibration Equipment Certificate of Calibration Conformance
Color
Tan
Voltage
14 V DC, 20 V AC, 30 V AC, 30 V DC
Operating Temp. Range (F)
-40 to 150
Type
Duct
For Use With
C450RCN-1C
Corrosion Resistant
Yes
Includes Temperature Sensor
Yes
Maximum Operating Temperature
140 Degrees F
Application
Humidity Monitoring
Output Signal
0 to 5 VDC or 0 to 10 VDC, 1,000 ohm Maximum Load
Standards
CCN XAPX, CE Certified, E27734, IEC 60730-2-13, UL 2043, UL Listed, UL 60730-1
Minimum Humidity
0 %
Minimum Operating Temperature
32 Degrees F
Sensor Shape
Square
Maximum Humidity
100 %
Maximum Temperature
140 Degrees F
Frequency
50 Hz, 60 Hz
Temperature Accuracy
+/-1.00 Degrees F
Humidity Accuracy
+/-3% RH for 20% to 80% RH at 77 Degrees F; +/-5% RH for 10% to 20% and 80% to 90% RH at 77 Degrees F
Compatible Manufacturer Model Number
C450RCN-1C
Minimum Temperature
32 Degrees F
Temperature Differential
+/-1 Degrees F at 70 Degrees F
Indoor/Outdoor
Indoor
Compatible Brand and Series
ACC-BRKT-100 - Mounting Bracket, ACC-CBL-100 Wiring Harness, C450RCN-1C Reset Control Modules
Electrical Connection Type
Screw Terminals
Product Type
Duct Temperature and Humidity Sensor
Relative Humidity/Dew Point Output
0 to 10V DC
Minimum Sensing Temperature
-40 Degrees F
Features
User-Selectable Output Voltage Range
NIST Traceable Certificate
NIST Traceable Certified
Housing Material
Plastic
Power Required
12 to 30V DC, 18 to 30V AC
Sensing Element Type
Silicon
Includes Power Supply
Power Supply Included
Housing Color
Blue
Loop Resistance
1,035 ohm
Measurement Type
Single
RH Sensor
Thermal
Display Type
None
Relative Humidity Range
20 to 80%
Relative Humidity Accuracy
+/-3% of Full Scale
Series
HE-69xx
Maximum Sensing Temperature
212 Degrees F
For Use With Building Automation Systems
Building Automation System Compatible

Description

Humidity Sensor, Display Type None, Sensing Element Type Silicon, Mounting Location Duct Mount, Housing Material Plastic, Housing Color Blue, Probe Length 6 in, Temperature Accuracy +/-1.00 Degrees F, Electrical Connection Type Screw Terminals, Maximum Sensing Temperature 212 Degrees F, Minimum Sensing Temperature -40 Degrees F, For Use With Building Automation Systems Building Automation System Compatible, Loop Resistance 1,035 ohm, Measurement Type Single
