  11. Temperature Control, Open/Close on Rise, -35 to 55 F Degrees, SPDT, 24V AC
This item is Discontinued.
Johnson Controls Temperature Control, Open/Close on Rise, -35 to 55 F Degrees, SPDT, 24V AC A350BA-1C

Temperature Control, Open/Close on Rise, -35 to 55 F Degrees, SPDT, 24V AC (Discontinued)

  • Mfr # A350BA-1C
  • Zoro # G7124844
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
A350BA-1C
Zoro #
G7124844
UPC #
-
Country of Origin
Mexico

Dimensions

Width
2 13/32 in
Height
5 in
Depth
2 13/32 in
Overall Length
5"
Digit Size
Standard
Overall Depth
2 3/8 in
Overall Height
5 in
Overall Width
2 3/8 in

Details

Item
Temperature Control
Switch Action
Open/Close on Rise
Type
Heating/Cooling
Sensor Type
Temperature
Differential
0.5 Degrees to 17 Degrees F
Voltage
24V AC
Display Type
Analog
Number of Relay Inputs
0
Thermostat Control Range
-35 Degrees to 55 Degrees F
For Use With
Suitable for Temperature Control in Refrigeration Applications
Includes
A99BC-25C Temperature Sensor
Switch Type
SPDT
Input Voltage
120V AC, 240V AC
Color
Gray
Thermostat Voltage
24 to 277V AC
Full Load Amps @ 240VAC
4.9 A
Control Range
-35 to 55 F Degrees
Inductive Amps @ 208V
4.9 A
Thermostat Heating/Cooling
Heating/Cooling
Remote Sensing Bulb Included
Yes
Inductive Amps @ 240V
4.9 A
Inductive Amps @ 120V
9.8 A
Remote Sensing Capability
Yes
Standards
CCN XAPX, UL
Contact Rating Resistive @ 240V
10 A
Pilot Duty Contacts (VA)
125 VA
Thermostat Programmable
No
Contact Rating Resistive @ 277V
10 A
Thermostat Item
Line Voltage Mechanical Thermostat
Locked Rotor Amps @ 120V
58.8 A
Locked Rotor Amps @ 240V
29.4 A
Resistive Amps @ 208VAC
10 A
Contact Rating Resistive @ 120V
10 A
Enclosure Type
NEMA 1
Thermostat Switch Type
SPDT
Full Load Amps @ 120VAC
15 A
Number of Switches
1
Number of Relay Outputs
0
Number of Stages
Single
Agency Compliance
UL, cUL
Thermostat Type
Mechanical
Application
Beverage Coolers, Chiller Control, Cooling Tower Control, Refrigeration, Temperature Sensing and Control
Dual Transformer Compatible
No
Dehumidification Control
No
Humidification Control
No
Features
Field Selectable Heat/Cool Mode, Adjustable Set Point and Differential, LED Indication of Relay Status, (5) Pin Connectors
Control Type
Exposed Dial
Voltage Range
24 to 277VAC
Temperature Scale
Fahrenheit
Mounting Direction
Vertical
Temperature Readout
No
Mounting Direction/Shape
Vertical
Electrical Connection Type
5-Pin Connector
Housing Material
Silicon
Compatible System Type
Electric Forced Air Furnaces
Maximum Control Temperature
130 Degrees F
Differential Type
Adjustable
Minimum Control Temperature
-30 Degrees F
Operating Humidity Range
0% to 95%
Operating Temperature Range
30 Degrees to 150 Degrees F
Housing Color
Gray
Pilot Duty Rating
125 VA
Shape
Rectangle
Frequency
50 Hz, 60 Hz
Sensor Location
Remote
Number of Sensor Inputs
1
Variable Output Voltage
No
Horsepower @ 240V AC
1/2 hp
Horsepower @ 120V AC
1/2 hp
Resistive Load Current @ 120V
58.8 A
Number of Sensors Included
1
Temperature Control Function
Heat and Cool
Full Load Current @ 120V AC
9.8 A
NEMA Rating
1
Contact Form
SPDT
Maximum Temperature Differential Setting
30 Degrees F
IP Rating
IP20
Minimum Temperature Differential Setting
1 Degrees F
Resistive Load Current @ 240V
29.4 A
Ambient Humidity
0% to 95% RH
Full Load Current @ 240V AC
4.9 A
Product Type
Temperature Control
Number of SPDT Outputs
1
Compatible with Series
350

Description

Temperature Control, Temperature Control Function Heat and Cool, Product Type Temperature Control, Number of Stages Single, Contact Form SPDT, NEMA Rating 1, IP Rating IP20, Maximum Control Temperature 130 Degrees F, Minimum Control Temperature -30 Degrees F, Maximum Temperature Differential Setting 30 Degrees F, Minimum Temperature Differential Setting 1 Degrees F, Display Type Analog, Input Voltage 120V AC, 240V AC, Variable Output Voltage No, Overall Height 5 in, Overall Width 2 3/8 in

Restrictions

This item has been restricted from sale in the following states: CA
