Shop JOHNSON LEVEL & TOOL

Cross Line Laser, Int, Green, 150 ft.

  • Mfr # 40-6232

  • Zoro # G2840162

product price:  $1,393.99
/ea
Free Shipping & Returns

Key Features

Laser Usage Environment
Interior
Laser Projection
Horizontal, Vertical
Leveling Type
Manual Leveling
Number of Beams
2
Number of Dots
0
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
40-6232
Zoro #
G2840162
UPC #
049448062324
Country of Origin
United States

Dimensions

Height
1 3/8 in
Length
4 in
Width
3/4 in
Thread Size
1/4"-20
Overall Depth
4 in
Tripod Thread Size
1/4"-20
Overall Height
1 3/8 in
Overall Width
3/4 in

Details

Item
Cross Line Laser
Laser Usage Environment
Interior
Laser Projection
Horizontal, Vertical
Leveling Type
Manual Leveling
Number of Beams
2
Number of Dots
0
Number of Lines
2
Laser Color
Green
Range w/o Detector
150 ft
Power Source
110V AC
Visual/Audible Indicators
Yes
IP Rating
IP65
Includes
Adapter, Bracket
Laser Class
Class 2
Preset Angle
None
Interior/Exterior
Interior
Horizontal/Vertical
Horizontal and Vertical
Accuracy
+/-1/16 in @ 10 ft
Total Number of Vials
0
Beam Color
Green
Features
Cylindrical Lens Technology - Solid Glass Optical System Draws a Continuous Line at Any Distance, Hard Anodized - Scratch Resistance Housing Laser Diode - Rated for 10,000 Hours of Operation or 5 Years Normal Operating Condition, Line Fan Angle - 70 Degrees, Line Widths - 1/16 in, Push On/Off Switch - Turn Unit on and Off with out having to Disconnect Power
Plumb Up
No
Number of Scanning Modes
2
Auto Shutoff
No
Number of Plumb Vials
0
Plumb Down
No
Number of 45 Degree Vials
0
Number of Level Vials
0
Material
Aluminum
Use Location
Indoor
Laser Output
Less Than or Equal To 1 mW
Indoor Range - Maximum
150 ft
Number of Planes
0
Mount Type
Mounting Bracket
Working Range without Detector - Maximum
150 ft
Bluetooth
Not Bluetooth Compatible
Number of 45 Vials
0
Includes Batteries
Batteries Not Included
Laser Beam Color
Green
Level Indicators
Audible, Visual
Automatic Shutoff
No
Weight
7.5 oz
Outdoor Range - Maximum
150 ft

Description

The Johnson 40-6232 Cross Line Laser is a quality tool that will meet the demands of your next project. It has an accuracy of +/-1/16 in at 10 ft and can be used both indoors and outdoors. With cylindrical lens technology, this laser level offers excellent visibility. The hard anodized scratch resistant housing protects the interior from wear and tear. This green laser has a height of 1 3/8 in., length of 4 in., and laser color of green. The beam can be projected horizontally or vertically for precise results. The Johnson 40-6232 Cross Line Laser is a quality tool you will want to equip yourself with for your next project.
