Shop JOMAR VALVE

2 Piece, Full Port, Press Connection, De

  • Mfr # 100-203SSG-IH

  • Zoro # G722324306

product price:
$
135.99
/ea
Free Shipping & Returns

Key Features

Connection Size - Side 1
1/2 in
NSF Certifications for Food and Drinking Water
NSF 61
Stem Material
316 Stainless Steel
Vacuum Service Rating
29 in Hg
Handle Height
2.9 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
100-203SSG-IH
Zoro #
G722324306
UPC #
662527312464
Country of Origin
United States
NSF Certifications for Food and Drinking Water
NSF 61
Stem Material
316 Stainless Steel
Vacuum Service Rating
29 in Hg
Ball Port Style
Full Port
Cleaned and Bagged
Not Cleaned and Bagged
Connection Type - Side 2
Press
Operating Temperature - Maximum
250 Degrees F
Maximum Pressure - Steam
Not Rated
Seat Material
PTFE
Coefficient of Volume (Cv)
16.82
Valve Ways
2-Way
Ball Material
316 Stainless Steel
Body Material
Brass
Valve Body Style
Straight
Connection Type - Side 1
Press
Connection Gender - Side 2
Female
Valve Construction
Two-Piece
Handle Material
Nylon
Connection Gender - Side 1
Male
Seal Material
FKM
For Media
Gas, Oil, Water
Handle Type
Lever
Stem Type
Blowout Resistant
Maximum Pressure - Operating
250 psi
Item
Manual Two-Way Ball Valve
Standards
Conforms to IAPMO PS 117, ISO 6509, NSF 372, NSF 61 - Annex G, NSF 61-8, UL-2043 Certified Insulated Handle
Handle - Locking
Locking

Description

Manual Two-Way Ball Valve, Body Material Brass, For Media Gas, Oil, Water, Valve Construction Two-Piece, Nominal Valve Size 1/2 in, Valve Body Style Straight, 3-A Standard Compliance Not Applicable, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 250 psi, Maximum Pressure - Steam Not Rated, Maximum Pressure - Combustible Gas Not Applicable, Vacuum Service Rating 29 in Hg, Ball Material 316 Stainless Steel, Ball Port Style Full Port, Handle - Locking Locking
