Shop JOMAR VALVE

2 Piece, Full Port, Press Connection, De

  • Mfr # 100-205SSG

  • Zoro # G522324346

product price:
$
149.99
/ea
Free Shipping & Returns

Key Features

Connection Type - Side 1
Press
Ball Port Style
Full Port
Body Material
Brass
Coefficient of Volume (Cv)
52.2
NSF Certifications for Food and Drinking Water
NSF 61
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
100-205SSG
Zoro #
G522324346
UPC #
662527307248
Country of Origin
United States
Connection Type - Side 1
Press
Ball Port Style
Full Port
Body Material
Brass
Coefficient of Volume (Cv)
52.2
NSF Certifications for Food and Drinking Water
NSF 61
Handle Material
Steel
Cleaned and Bagged
Not Cleaned and Bagged
Connection Gender - Side 2
Female
Seal Material
FKM
Stem Material
316 Stainless Steel
Item
Manual Two-Way Ball Valve
Standards
Conforms to IAPMO PS 117, ISO 6509, NSF 372, NSF 61 - Annex G, NSF 61-8
Valve Construction
Two-Piece
Ball Material
316 Stainless Steel
Maximum Pressure - Steam
Not Rated
Valve Ways
2-Way
Connection Type - Side 2
Press
For Media
Gas, Oil, Water
Valve Body Style
Straight
Handle - Locking
Locking
Operating Temperature - Maximum
250 Degrees F
Handle Type
Lever
Connection Gender - Side 1
Male
Seat Material
PTFE
Maximum Pressure - Operating
250 psi
Stem Type
Blowout Resistant
Vacuum Service Rating
29 in Hg

Description

Manual Two-Way Ball Valve, Body Material Brass, For Media Gas, Oil, Water, Valve Construction Two-Piece, Nominal Valve Size 1 in, Valve Body Style Straight, 3-A Standard Compliance Not Applicable, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 250 psi, Maximum Pressure - Steam Not Rated, Maximum Pressure - Combustible Gas Not Applicable, Vacuum Service Rating 29 in Hg, Ball Material 316 Stainless Steel, Ball Port Style Full Port, Handle - Locking Locking
