  11. Warning Light, Red, LED, 12 to 24V, Not Applicable FPM, Not Applicable Dia., Universal
J.W. Speaker Warning Light, Red, LED, 12 to 24V, Not Applicable FPM, Not Applicable Dia., Universal 527 RED - main

Warning Light, Red, LED, 12 to 24V, Not Applicable FPM, Not Applicable Dia., Universal

  • Mfr # 527 RED

  • Zoro # G0084668

product price: $432.99
/ea
Free Shipping & Returns

Key Features

Color
Red
Lamp Type
LED
Power Source
Wire
Lamp Life
40,000 hr
Lens Material
Glass
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
527 RED
Zoro #
G0084668
UPC #
-
Country of Origin
United States

Dimensions

Height
4 7/8 in
Depth
4 1/32 in
Width
10 3/16 in
Overall Depth
4 1/32 in
Overall Width
4 7/8 in
Overall Length
10 3/16 in
Footprint Width
4 7/8 in
Footprint Length
10 3/16 in

Details

Item
Warning Light
Color
Red
Lamp Type
LED
Power Source
Wire
Lamp Life
40,000 hr
Lens Material
Glass
Housing Material
Xenoy
Standards
BAA Compliant, IEC
Voltage
12 to 24V
Mounting
Universal
Operating Temp.
-40 Degrees to 149 Degrees F
Rating
IP69K
Light Output
670 Lumens
Lens Design
Rectangular
Current Drawn
1.6 to 0.9A AC
Product Type
Warning Light
Connection Type
2-Pin Deutsch Socket
Light Operating Mode
Steady
Footprint Shape
Rectangle
Light Intensity
670 lm
Lamp Color
Red
Brightness Selection
Fixed Brightness
Operating Temperature - Minimum
-40 Degrees F
Mounting Mechanism
Screw
Includes Mounting Hardware
Mounting Hardware Included
IP Rating
IP69K
For Location
Indoor, Outdoor
Lifespan
40,000 hr
Operating Current
0.850 A @ 24V DC, 1.6 A @ 12V DC
Control Protocol
Direct Wire
Operating Temperature - Maximum
149 Degrees F
IO-Link Compatibility
Not IO-Link Compatible
Lens Color
Clear
Lens Shape
Bar
Mounting Style
Surface Mount
Requires Base
Base Not Required
Housing Color
Black
Light Source
LED
Operating Voltage
12 to 24V

Description

Warning Light, Color Red, Lamp Type LED, Flashes per Minute Not Applicable, Light Output 670 Lumens, Lamp Life 40,000 hr, Lens Design Rectangular, Lens Material Glass, Housing Material Xenoy, Mounting Universal, Operating Temp. -40 Degrees to 149 Degrees F, Rating IP69K, Power Source Wire, Current Drawn 1.6 to 0.9A AC, Width 10 3/16 in, Depth 4 1/32 in, Height 4 7/8 in
