Shop TRITAN

Mini Ball Brg, 635, 5mm Bore, Alloy Stl

  • Mfr # 635 ZZ PRX

  • Zoro # G4576671

product price:
$
7.59
/ea

Key Features

Type
Shielded
Material
52100 Steel
Bore Dia.
5mm
Outside Dia.
19mm
Width
6mm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
635 ZZ PRX
Zoro #
G4576671
UPC #
888569115515
Country of Origin
China
Type
Shielded
Material
52100 Steel
Static Load Capacity (Lb.)
200 lb
Max. RPM
32,000 RPM
Dynamic Load Capacity (Lb.)
530 lb
Item
Radial Ball Bearing
Shield Material
Stainless Steel
ABEC Tolerance
1
Lubrication
MultiTemp SRL
Temp. Range (F)
-40 Degrees to 302 Degrees F
Miniature Bearing
Yes
ABEC Rating
1
Ball Material
Steel
System of Measurement
Metric
Bearing Industry Number
635
Static Radial Load Capacity
200 lbf
For Environment
Oily/Greasy
Standards
AFBMA, ISO Certified 9001
Ball Material Grade
AISI 52100
Minimum Temperature
-40 Degrees F
Maximum Temperature
248 Degrees F
Closure
Double Shielded
Includes Retaining Ring
No
Lubricant Material
Mobil Polyrex EM
Retaining Ring Groove
No
Maximum Speed
40,000 RPM
Ring Material
Alloy Steel
Ring Material Grade
AISI 52100
Dynamic Radial Load Capacity
530 lbf
Cage Type
Shielded
Temp. Range
-20 to +212° F
Cage Material
Steel
Number of Rows
One
Industry Number
635 ZZ
Bearing Lubrication
Maintenance-Free
Series
600 Series
Flange Type
Non-Flanged
Outer Ring Type
Shield/Seal Groove
Internal Clearance
CN

Description

Radial Ball Bearing, Bearing Industry Number 635, Bore Diameter 5 mm, Closure Double Shielded, For Environment Oily/Greasy, Outer Ring Width 6 mm, Outside Diameter 19 mm, Ring Material Alloy Steel, System of Measurement Metric, Cage Material Steel, ABEC Rating 1, Ball Material Steel, Ball Material Grade AISI 52100, Bore Diameter Tolerance +0.000/-0.008 mm, Cage Type Shielded, Dynamic Radial Load Capacity 530 lbf, Flange Diameter Not Applicable, Flange Thickness Not Applicable
