CAD Viewer & Download Files
Circuit Breaker, CLB Series, 15A, 1 Pole, 125/250V AC, 0.2kA at 240V AC, C Curve
Mfr # CLB-153-27E3N-W-A/15
Zoro # G1254827
CAD Available
product price: $4.99
/eaKey Features
CAD Drawing
Series
CLB
Number of Poles
1
AC Voltage Rating
125/250V AC
Circuit Breaker Type
Thermal
Phase
1
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
CLB-153-27E3N-W-A/15
Zoro #
G1254827
UPC #
-
Country of Origin
Taiwan, Province of China
Dimensions
Width
0.57 in
Depth
2.31 in
Height
1.38 in
Max. Wire Size
14 AWG
Panel Cutout Size
0.343 in x 0.382 in
Mounting Hole Thread Size
3/8"-27
Max. Panel Thickness
0.118 in
Length
1.38 in
Description
Panel Mount Circuit Breaker, Amps 15 A, AC Voltage Rating 125/250V AC, Terminal Connection 1/4 in Tab, DC Voltage Rating 32V DC, Thermal, Number of Poles 1, Circuit Breaker Actuator Push Button, Max. AIR Rating Not Rated, Curve Type Medium, Phase Single, Mounting Type 3/8 in Collar, Actuator Color White, Actuator Legend Press to Reset, Panel Cutout Size 0.343 in x 0.382 in, Max. Panel Thickness 0.118 in, Mounting Hole Thread Size 3/8 In.-27, Max. Wire Size 14 AWG, Length 1.38 in, Width 0.57 in
