Circuit Breaker, CMB Series, 5A, 1 Pole, 125/250V AC, Not Rated, C Curve
Mfr # CMB-053-27G3N-W-A/05
Zoro # G2950367
CAD Available
product price: $5.29
/eaKey Features
CAD Drawing
Series
CMB
Number of Poles
1
AC Voltage Rating
125/250V AC
Circuit Breaker Type
Thermal
Phase
1
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
CMB-053-27G3N-W-A/05
Zoro #
G2950367
UPC #
-
Country of Origin
Taiwan, Province of China
Dimensions
Width
0.55 in
Depth
1.78 in
Height
1.15 in
Max. Wire Size
14 AWG
Mounting Hole Thread Size
3/8"-27
Panel Cutout Size
0.343 in x 0.382 in
Max. Panel Thickness
0.118 in
Length
1.15 in
Description
Panel Mount Circuit Breaker, Amps 5 A, AC Voltage Rating 125/250V AC, Terminal Connection 1/4 in Tab, DC Voltage Rating 32V DC, Thermal, Number of Poles 1, Circuit Breaker Actuator Push Button, Max. AIR Rating Not Rated, Curve Type Medium, Phase Single, Mounting Type 3/8 in Collar, Actuator Color White, Actuator Legend Press to Reset, Panel Cutout Size 0.343 in x 0.382 in, Max. Panel Thickness 0.118 in, Mounting Hole Thread Size 3/8 In.-27, Max. Wire Size 14 AWG, Length 1.15 in, Width 0.55 in
