  11. Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 2,000 sq ft, Fluorescent, Incandescent, LED
Sensorswitch Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 2,000 sq ft, Fluorescent, Incandescent, LED CMR PDT 10 - main

Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 2,000 sq ft, Fluorescent, Incandescent, LED

  • Mfr # CMR PDT 10

  • Zoro # G3102242

product price: $146.99
/ea
Free Shipping & Returns

Key Features

Sensing Technology
Passive Infrared (PIR)/Microphonic
Time Delay - Motion Sensor
30 sec to 20 min
Color
White
Viewing Angle
360 Degrees
Watts @ 277V
1200
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CMR PDT 10
Zoro #
G3102242
UPC #
745975809530
Country of Origin
Mexico

Dimensions

Overall Depth
1.55 in
Minimum Mounting Height
7 ft
Maximum Mounting Height
15 ft
Overall Width
4.55 in

Details

Sensing Technology
Passive Infrared (PIR)/Microphonic
Time Delay - Motion Sensor
30 sec to 20 min
Color
White
Item
Occupancy Sensor
Viewing Angle
360 Degrees
Watts @ 277V
1200
Lighting Technology
Fluorescent, Incandescent, LED
Watts @ 120V
800
For Use With
Fluorescent and Incandescent Lighting Loads
Max. Capacity @ 277VAC
1200W (Fluorescent, Incandescent)
Max. Capacity @ 120VAC
800W (Fluorescent, Incandescent)
Time Delay
Adaptive/Manual
Sensor Type
Passive Infrared/Microphonic
Standards
BAA, CA Title 24 Compliant, RoHS Compliant
Coverage Angle - Motion Sensor
360 Degrees
Includes
(2) Self Tapping Screw
Communication Method
Hard Wired
Wall Plate
Not Included
Installation Location
Ceiling Mount
Time Delay Adjustment Method
Adaptive, Manual
Manufacturer Warranty
5 yr Limited
Sensor Operation
Occupancy, Photocell
Minimum Time Delay
30 sec
Series
CMR
Maximum Operating Temperature
140 Degrees F
Coverage Angle
360 Degrees
Maximum Coverage Area
2,000 sq ft
Maximum Time Delay
20 min
Minimum Operating Temperature
14 Degrees F
Load Rating @ 277V AC
1,200W
Load Rating @ 120V AC
800W/6.67A, Incandescent
Coverage Type
Large Motion
Load Rating @ 480V AC
80mA
Compliance Listing
BAA
Control Protocol
0-10V
Mounting Type
Flush, Surface
Environmental Listing
High Humidity
Application Type
Automotive & Parking, Education, Government, Healthcare, Hospitality, House of Worship, Manufacturing, Offices & Banks, Power & Gas, Residential, Retail, Roadways, Bridges & Tunnels, Sports and Recreation, Transportation, Warehouses
Voltage Rating
208, 347, 480
Finish
Matte
Operating Voltage
120/220/230/277V

Description

Occupancy Sensor, Sensing Technology Passive Infrared (PIR)/Microphonic, Operating Voltage 120/220/230/277V, Maximum Coverage Area 2,000 sq ft, Maximum Mounting Height 15 ft, Load Rating @ 120V AC 800W/6.67A (Incandescent), Communication Method Hard Wired, Color White, Includes (2) Self Tapping Screw, Sensor Operation Occupancy, Lighting Technology Fluorescent, Incandescent, LED, Installation Location Ceiling, Standards BAA, CA Title 24 Compliant, RoHS Compliant, Overall Diameter Not Applicable
