  11. Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 500 sq ft, Fluorescent, Incandescent, LED
Sensorswitch Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 500 sq ft, Fluorescent, Incandescent, LED CMR PDT 9 - main

Ceiling Mount Sensor, Occupancy, Photocell, Hard Wired, White, 500 sq ft, Fluorescent, Incandescent, LED

  • Mfr # CMR PDT 9

  • Zoro # G2279934

product price: $92.15
/ea
Free Shipping & Returns

Key Features

Sensing Technology
Passive Infrared (PIR)/Microphonic
Time Delay - Motion Sensor
30 sec to 20 min
Lighting Technology
Fluorescent, Incandescent, LED
Viewing Angle
360 Degrees
Sensor Type
Passive Infrared/Microphonic
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CMR PDT 9
Zoro #
G2279934
UPC #
745975809448
Country of Origin
Mexico

Dimensions

Fixture Height
1.5
Fixture Length
4.5
Fixture Width
4.5
Overall Depth
1.55 in
Minimum Mounting Height
8 ft
Maximum Mounting Height
15 ft
Overall Width
4.55 in

Details

Sensing Technology
Passive Infrared (PIR)/Microphonic
Time Delay - Motion Sensor
30 sec to 20 min
Lighting Technology
Fluorescent, Incandescent, LED
Viewing Angle
360 Degrees
Sensor Type
Passive Infrared/Microphonic
Watts @ 277V
1200
Color
White
Standards
BAA, CA Title 24 Compliant, RoHS Compliant
Coverage Angle - Motion Sensor
360 Degrees
Watts @ 120V
800
Item
Occupancy Sensor
For Use With
Fluorescent and Incandescent Lighting Loads
Max. Capacity @ 277VAC
1200W (Fluorescent, Incandescent)
Max. Capacity @ 120VAC
800W (Fluorescent, Incandescent)
Time Delay
Adaptive/Manual
Includes
(2) Self Tapping Screw
Communication Method
Hard Wired
Wall Plate
Not Included
Maximum Operating Temperature
140 Degrees F
Series
CMR
Maximum Time Delay
20 min
Load Rating @ 480V AC
80mA
Minimum Time Delay
30 sec
Maximum Coverage Area
500 sq ft
Load Rating @ 277V AC
1,200W
Installation Location
Ceiling Mount
Coverage Angle
360 Degrees
Sensor Operation
Occupancy, Photocell
Load Rating @ 120V AC
800W/6.67A, Incandescent
Coverage Type
Small Motion
Manufacturer Warranty
5 yr Limited
Time Delay Adjustment Method
Adaptive, Manual
Minimum Operating Temperature
14 Degrees F
Motion Sensing Distance
12
Daylight Sensing
No
Mounting
Flush,Surface
Environment
Indoor
Batteries Included
No
Compliance Listing
BAA
Motion Sensing Field of View
360 degrees
Lens Material
Plastic
Voltage Rating
208, 347, 480
Shape
Round
Environmental Listing
High Humidity
Relay Configuration
Single Pole
Control Protocol
0-10V
Is Motion Sensing Adjustable
Yes
Application Type
Automotive & Parking, Education, Government, Healthcare, Hospitality, House of Worship, Manufacturing, Offices & Banks, Power & Gas, Residential, Retail, Roadways, Bridges & Tunnels, Sports and Recreation, Transportation, Warehouses
Mounting Location
Ceiling
Contains Lithium Battery
No
Finish
Matte
Mounting Type
Flush, Surface
Operating Voltage
120/220/230/277V

Description

Occupancy Sensor, Sensing Technology Passive Infrared (PIR)/Microphonic, Operating Voltage 120/220/230/277V, Maximum Coverage Area 500 sq ft, Maximum Mounting Height 15 ft, Load Rating @ 120V AC 800W/6.67A (Incandescent), Communication Method Hard Wired, Color White, Includes (2) Self Tapping Screw, Sensor Operation Occupancy, Lighting Technology Fluorescent, Incandescent, LED, Installation Location Ceiling, Standards BAA, CA Title 24 Compliant, RoHS Compliant, Overall Diameter Not Applicable
