  9. Thermal Imager Camera, 40 mK, 640 x 480 Display, 24 Degrees x 18 Degrees
Flir Thermal Imager Camera, 40 mK, 640 x 480 Display, 24 Degrees x 18 Degrees FLIR E54-24-NIST - main

Thermal Imager Camera, 40 mK, 640 x 480 Display, 24 Degrees x 18 Degrees

  • Mfr # FLIR E54-24-NIST

  • Zoro # G711242512

product price: $8,569.99
/ea
Free Shipping & Returns

Key Features

Field of View
24 Degrees x 18 Degrees
Features
Data Logging, Image Notation, Image Sketching, Multi Spectral Dynamic Imaging (MSX(R))
Thermal Sensitivity
40 mK
Focus Method
Manual
Display Resolution
640 x 480
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FLIR E54-24-NIST
Zoro #
G711242512
UPC #
-
Country of Origin
Estonia

Dimensions

Display Size
4 in
Manufacturer Warranty Length
2 yr

Details

Item
Thermal Imager Camera
Field of View
24 Degrees x 18 Degrees
Features
Data Logging, Image Notation, Image Sketching, Multi Spectral Dynamic Imaging (MSX(R))
Thermal Sensitivity
40 mK
Focus Method
Manual
Display Resolution
640 x 480
Visual Light Resolution
5 MP
File Formats
CSQ, H.264, JPEG, MJPEG, MPEG4
Removable Memory Card
8GB SD
Includes
(2) Batteries, 8 GB SD Card, Battery Charger, Front Lens Cap, Hard Transport Case, Infrared Camera with Lens, Lanyards, Power Supplies, USB 2.0 A to USB C Cable, USB C to HDMI Cable, USB C to USB C Cable
Standards
EN/UL/CSA/PSE 60950-1
Temperature Alerts
High Temperature, Low Temperature, Normal Body Temperature
Digital Display Screen Type
LCD Touchscreen
Maximum Emissivity Setting
1.00
Calibration Certificate Type
NIST, Traceable with data
Emissivity Adjustability
Adjustable
Minimum Operating Temperature Degrees F
5 Degrees F
Alert Type
Digital Display, Sound
Minimum Focus Distance
0.15 m
Frame Rate
30 Hz
Minimum Emissivity Setting
0.01
Maximum Temperature Measured Degrees F
1,202 Degrees F
Lens Angles Included
24 Degrees
Intrinsic Safety
Not Specified Intrinsically Safe
Maximum Operating Temperature Degrees F
122 Degrees F
Accuracy Degrees F
+/-2.0% of Reading or +/-3.6 Degrees F Whichever is Greater
Interface
SD Card, USB, Wireless
Minimum Temperature Measured Degrees F
-4 Degrees F
Infrared Resolution
320 x 240
Data Transfer Type
Wired, Wireless
Battery Voltage
3V
Battery Chemistry
Lithium Ion
Maximum Temperature Measured Degrees C
650 Degrees C
Series
Exx
Battery Run Time
2.5 hr
Batteries Included
Yes
Auto Power Off
Yes
Number of Batteries Required
2
Accuracy Degrees C
+/-2.0% of Reading
Minimum Temperature Measured Degrees C
-20 Degrees C

Description

Infrared Camera, Temperature Alerts High Temperature, Low Temperature, Normal Body Temperature, Frame Rate 30 Hz, Visual Light Resolution 5 MP, Calibration Certificate Type NIST, Alert Type Light, Sound, Data Transfer Type Wired, Wireless, Digital Display Screen Type LCD Touchscreen, Emissivity Adjustability Adjustable, Maximum Emissivity Setting 1.00, Minimum Emissivity Setting 0.01, Thermal Sensitivity 40 mK, Minimum Focus Distance 0.15 m, Minimum Operating Temperature Degrees F 5 Degrees F

Restrictions

Hazardous material
