- MFR #
- LRD3363
- Zoro #
- G3345237
- UPC #
- 785901208334
- Country of Origin
- Korea, Republic of
- Item
- Overload Relay
- Auxiliary Contact Form
- 1NC/1NO
- Minimum Overload Relay Current Setting
- 63 A
- Maximum Overload Relay Current Setting
- 80 A
- Trip Class
- 10A
- Overload Protection Type
- Thermal
- Maximum Voltage Rating
- 1000V AC
- Standards
- CSA C22.2 No 60947-4-1, CSA C22.2 No 60947-5-1, EN 50495, EN/IEC 60947-4-1, EN/IEC 60947-5-1, GB/T 14048.4, GB/T 14048.5, REACH, RoHS, UL 60947-4-1, UL 60947-5-1
- For Use With
- LC1D65 thru LC1D80 Contactor
- Sensing Method
- Bimetallic
- Trip Class - Overload
- 10
- Number of Poles
- 3
- Use With - Contactors and Starters
- Mfr. Series LC1D65 to LC1D80 Contactors
- Features
- Single Phase Sensitivity; Differential
- Starter Type
- IEC
- Relay Application
- motor protection
- Mechanical Robustness
- vibrations6 Gn IEC 60068-2-6 || shocks15 Gn for 11 ms IEC 60068-2-7
- Product Certifications
- IEC || UL || CSA || CCC || EAC || ATEX INERIS || UKCA
- Device Short Name
- LRD
- Range
- TeSys
- Tightening Torque
- control circuit 1.7 N.m screw clamp terminals || power circuit 9 N.m screw clamp terminals
- Product Or Component Type
- differential thermal overload relay
- Network Type
- DC || AC
- Climatic Withstand
- IACS E10
- Flame Retardance
- V1 conforming to UL 94
- Ambient Air Temperature For Storage
- -60-70°C
- Ambient Air Temperature For Operation
- -20-60°C without derating IEC 60947-4-1
- Dielectric Strength
- 2.2 kV 50 Hz IEC 60947-1
- Product Name
- TeSys LRD || TeSys Deca
- Control Type
- Red push-button stop || Blue push-button reset
- Connections - Terminals
power circuit screw clamp terminals 1 4-35 mm² flexible without cable end || power circuit screw clamp terminals 1 4-35 mm² flexible with cable end || power circuit screw clamp terminals 1 4-35 mm² solid without cable end || control circuit screw clamp terminals 2 1-2.5 mm² flexible without cable end || control circuit screw clamp terminals 2 1-2.5 mm² flexible with cable end || control circuit screw clamp terminals 2 1-2.5 mm² solid without cable end
- Phase Failure Sensitivity
- tripping current 130 % of Ir on two phase, the last one at 0
- Tripping Threshold
- 1.14 +/- 0.06 Ir IEC 60947-4-1
- Product Compatibility
- LC1D80 || LC1D95
- Thermal Overload Class
- class 10A IEC 60947-4-1
- Thermal Protection Adjustment Range
- 63-80 A
- Network Frequency
- 0 to 400 Hz
- Associated Fuse Rating
- 4 A gG signalling circuit || 4 A BS signalling circuit
- Permissible Current
- 0.72 A 500 V AC-15 signalling circuit || 0.06 A 440 V DC-13 signalling circuit
- Relay Style
- IEC
- Maximum Operating Temperature
- 140 Degrees F
- Compatible with Series
- TeSys Deca
- Mounting Style
- Direct To Contactor
- Reset Type
- Manual
- Terminal Connection Type
- Screw Clamp Terminals
- IP Rating
- IP20
- Minimum Operating Temperature
- -4 Degrees F
- Rated Insulation Voltage
- power circuit 1000 V IEC 60947-4-1 || power circuit 600 V CSA || power circuit 600 V UL
- Rated Operational Voltage
- 1000 V AC 0 to 400 Hz power circuit IEC 60947-4-1
- Conventional Free Air Thermal Current
- 5 A signalling circuit
- Trip Clss
- 10A
