Digital Multimeter, 600 V Max DC, 60 mV Max AC, TRMS, 6,000 Instrument Counts, EBTN with Bar Graph

  • Mfr # MM525

  • Zoro # G012469847

product price:  $98.15
/ea

Key Features

Display Type
LCD
Data Hold
Yes
Instrument Counts
6,000
Includes
(2) Batteries, Pouch Case, Temperature Probe, Test Leads
Standards
CE, RoHS
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
MM525
Zoro #
G012469847
UPC #
614395002978
Country of Origin
China

Dimensions

Manufacturers Warranty Length
1 yr
Overall Height
6.9 in
Battery Size
AA
Overall Width
3.2 in
Depth
1.9 in

Details

Item
Digital Multimeter
Display Type
LCD
Data Hold
Yes
Instrument Counts
6,000
Includes
(2) Batteries, Pouch Case, Temperature Probe, Test Leads
Standards
CE, RoHS
Auto Power Off
Yes
Audible Continuity
Yes
Diode Test
Yes
DC Voltage Measurement Resolution
0.01 mV
Temperature Measurement Resolution
1 Degrees F
Minimum Resistance Measurement
0 ohm
Minimum DC Voltage Measurement
0 V
Duty Cycle
Duty Cycle Test Included
Basic AC Current Accuracy
+/-0.7%
Capacitance Measurement Accuracy
+/-4.0% +10 digits
Minimum Operating Temperature
32 Degrees F
Removable Screen
No
Battery Voltage
3 V
Dustproof
No
AC Response Calculation
TRMS
Waterproof
No
Intrinsically Safe
No
Thermal Imaging
No
Instrument Safety Rating
CAT III 600V
Maximum DC Current Measurement
10 A
Maximum Storage Temperature
122 Degrees F
Basic DC Current Accuracy
+/-0.7%
Temperature Measurement Accuracy
+/-5
Weight
12.2 oz
Capacitance Measurement Resolution
0 nF
AC Current Measurement Resolution
0.1 uA
Minimum Temperature Measurement
-40 Degrees F
AC Voltage Measurement Resolution
0.01 mV
Parameters Measured
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Low Pass Filter, Low Input Impedance, Non-Contact Voltage, Resistance
Battery Access
Yes
Bar Graph Included
Yes
Maximum AC Current Measurement
10 A
Maximum Capacitance Measurement
100 mF
Minimum AC Voltage Measurement
0 V
Minimum DC Current Measurement
0 A
Resistance Measurement Resolution
0.1 ohm
Resistance Measurement Accuracy
+/-1.0% +2 digits
Minimum AC Current Measurement
0 A
Bluetooth Compatible
No
DC Current Measurement Resolution
0.1 uA
Maximum AC Voltage Measurement
600 V
Frequency Measurement Resolution
0 Hz
Basic AC Voltage Accuracy
+/-0.7%
Basic DC Voltage Accuracy
+/-0.7%
Maximum Resistance Measurement
60 megaohm
Batteries Included
Yes
Maximum Frequency Measurement
10 MHz
IP Rating
Not Rated
Minimum Storage Temperature
14 Degrees F
Frequency Measurement Accuracy
+/-0.1% +4 digits
Maximum DC Voltage Measurement
600 V
Minimum Capacitance Measurement
10 nF
Maximum Temperature Measurement
1,832 Degrees F
Minimum Frequency Measurement
10 Hz
Calibration Certificate Included
No Certification Included
Current Leakage Testing
No
Voltage Units
V
Special Features
60A Clamp Adapter Input can be used with any Adapter that has a 10mV/A Output, Built-In NCV Detector, Data Hold and Relative Mode, Low Battery Indicator, Low Pass Filter (LPF), True RMS
Current Units
A, uA
Temperature Types Measured
Temperature Degrees C, Temperature Degrees F
Data Logging
No
CAT Safety Rating
CAT III 600V
Includes Auto Sensing
No Auto Sensing Included

Description

Digital Multimeter, Audible Continuity Yes, Basic AC Voltage Accuracy +/-0.7 Percent, Basic DC Voltage Accuracy +/-0.7 Percent, Data Hold Yes, Basic DC Current Accuracy +/-0.7 Percent, Instrument Safety Rating CAT III 600V, Maximum AC Voltage Measurement 600 V, Maximum DC Voltage Measurement 600 V, Instrument Counts 6,000
