Coupling, Oldham Coupling Disc

  • Mfr # OD12/19-AT

  • Zoro # G1019243

product price:  $5.29
/ea

Key Features

Rated Torque
20 in-lb
Max. RPM
4,500 RPM
Disc Type
Acetal
Style
Oldham Coupling Disc
Outside Dia. (In.)
0.750
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
OD12/19-AT
Zoro #
G1019243
UPC #
634529059937
Country of Origin
United States

Dimensions

Outside Dia. (In.)
0.750
Outside Dia. (mm)
19.10
Fits Hub Outside Dia.
0.750 in / 19.1mm
Coupling Size
OD19, OD12
Outside Diameter
3/4 in
For Hub Diameter
3/4 in

Details

Rated Torque
20 in-lb
Max. RPM
4,500 RPM
Disc Type
Acetal
Style
Oldham Coupling Disc
Item
Motion Control Coupling
Torsional Stiffness (Deg./In.-Lbs.)
0.043
Item - Oldham Coupling Discs
Oldham Coupling Disc
Max. Angular Misalignment
0.5 Degrees
Max. Temp. Range (F)
150 Degrees F
Material
Acetal
Max. Axial Misalignment (In.)
+/-0.004
Finish
Plain
Max. Parallel Misalignment (In.)
0.008 in
Material - Discs
Acetal
Torque (In.-Lbs.)
20.00
Axial Motion
0.004 in
Weight
0.002666 lb
Application
Applications With High Parallel Misalignment (Up to 10% of the Coupling OD)
Zero Backlash
Yes
Features
High Torsional Stiffness, Highly Customizable Coupling, Three-Piece Design, Zero-Backlash
Mechanical Fuse Break
Yes
Maximum Torque
20 in-lb
System of Measurement
Inch
Parallel Misalignment
0.008 in
Maximum Operating Temperature
150 Degrees F
Torsional Stiffness
23.3 in-lb/Deg
Minimum Operating Temperature
-10 Degrees F
Disc Finish
Plain
Disc Material
Acetal
Full Bearing Support Required
Yes
For Misalignment Type
Angular, Axial, Parallel
Maximum Speed
4,500 RPM
Standards
Conflict Minerals Compliant, ISO 9001:2015, REACH Compliant, RoHS3 Compliant
Over-Standard Parallel Misalignment
0.075 in
Color
Black
Angular Misalignment
0.5 Degrees
Break Torque
93 in-lb

Description

Motion Control Coupling, Angular Misalignment 0.5 Degrees , Axial Motion 0.004 in, Coupling Size OD19, OD12, Outside Diameter 3/4 in, Over-Standard Parallel Misalignment 0.075 in, Parallel Misalignment 0.008 in, Break Torque 93 in-lb, Disc Material Acetal, Maximum Torque 20 in-lb, Torsional Stiffness 23.3 in-lb/Deg, System of Measurement Inch, Maximum Speed 4,500 RPM, For Hub Diameter 3/4 in, Application Applications With High Parallel Misalignment (Up to 10 Percent of the Coupling OD)
