Hubbell Wiring Device-Kellems Liquid Tight Connector, 1/2 in., Brown SHC1026 - main

Liquid Tight Connector, 1/2 in., Brown

  • Mfr # SHC1026

  • Zoro # G1307381

product price: $10.59
/ea

Key Features

Material
Aluminum
Box Connection
1/2 in MNPT
Gland Color Code
Brown
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Strain Relief Type
No External Strain Relief
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC1026
Zoro #
G1307381
UPC #
783585200262
Country of Origin
China

Dimensions

Length
2-3/64"
Cord Dia. Range
0.50 in to 0.63 in
Length - Box to End of Connector
1 1/2 in
Conduit Size
1/2"
Length - External Strain Relief
No External Strain Relief
Hub Size
1/2 in MNPT
Thread Size
1/2 in
Form Size
F3
Overall Length
2 1/16 in
Compatible Conduit Trade Size
1/2 in
Recommended Knockout Hole Size
.86"- .91" (21.8-23.0)
Dimension D
.64" (16.3) Throat Dia.
Dimension B
1.50" (38.1) Ref.
Dimension A
1.38" (35.1) Dia.
Cord Diameter Range
.50"- .63" (12.7-15.9)
Dimension E A/C
1.40" (35.6)
Dimension C
.55" (14.0)
Dimension E A/F
1.25" (31.7)
Display Size
1/2" NPT

Details

Item
Liquid Tight Cord Connector
Material
Aluminum
Box Connection
1/2 in MNPT
Gland Color Code
Brown
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Strain Relief Type
No External Strain Relief
Connector Type
Straight
Item - Cord Connector
Liquid Tight Cord Connector
Material - External Strain Relief
No External Strain Relief
Style - Connector
Straight
Number of Cords
1
Color
Brown
Material - Cord Connector
Aluminum
Insulated
No
Body Color - Cord Connector
Silver
Standards
CSA LR27378, UL E54218(M)
For Use With
Kellems Wire Management
IP Rating
IP66
Thread Gender
Male
Thread Type
NPT Thread
For Minimum Cable OD
0.5 in
Connection Orientation
Straight
Body Color
Silver
Grommet Color Code
Brown
Liquid Tight
Yes
Bushing Material
Neoprene
Compatible Conduit Type
Liquid Tight Cord Connector
For Maximum Cable OD
0.63 in
Body Material
Aluminum
Minimum Operating Temperature
-30 Degrees F
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Maximum Operating Temperature
225 Degrees F
Collar Material
Aluminum
Environmental Rating
Hazardous Locations
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Cord Connector Body Style
Straight Male
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Material/Style
Aluminum
Product Type
Cord Connectors
Effective Operating Temperature
-30°F to +225°F (34°C to +107°C)
Color Code
Brown
Number Of Conductors
Single
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Series
Standard Duty
Type
Straight Male
Application
Straight Male- Form 3
Industry Standard(s)
UL Listed
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
OEM Brand Name
Hubbell Wiring Device-Kellems
Performance
Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Material - Mounting Hardware
Locknut or Tapped Opening
Conductor Range
0.5-0.63 in (12.7-15.9 mm)
Item Type
Cord Connectors

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.50 in to 0.63 in, Box Connection 1/2 in MNPT, Material - Cord Connector Aluminum, External Strain Relief Material No External Strain Relief, Gland Color Code Brown, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 1/2 in, Insulated No, Standards CSA LR27378, UL E54218(M)
