Oval Eye Nut, 1"-8 Thread Size, 1-11/16 in Thread Lg, Steel, Black Oxide
Mfr # EN-10-HD
Zoro # G0444674
CAD Available
product price: $55.59
/eaKey Features
CAD Drawing
Thread Size
1"-8
Thread Length
1-11/16 in
Eye Shape
Oval
Material
Steel
Material Grade/Class
Not Graded
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
EN-10-HD
Zoro #
G0444674
UPC #
-
Country of Origin
United States
Dimensions
Thread Size
1"-8
Thread Length
1-11/16 in
Eye Inside Diameter
1 3/4 in
Eye Outside Diameter
3-3/4 in
Overall Height
4-27/32 in
Base Diameter
2.281 in
Base Height
1.688 in
Eye Thickness
1.031 in
Eye inside Diameter
1-3/4 in
Eye Outside Dia.
3 3/4 in
Eye Inside Dia.
1 3/4 in
Description
Eye Nut, Finish Black Oxide, Material Steel, Thread Size 1 In.-8, Thread Length 1 11/16 in, Eye Shape Oval, Eye Inside Diameter 1 3/4 in, Eye Outside Diameter 3 3/4 in, Overall Height 4 27/32 in, Working Load Limit 18,800 lb, System of Measurement Inch, Base Diameter 2.28 in, Base Height 1.69 in, Bore Type Threaded Tapped, Eye Thickness 1.03 in, Material Fabrication Drop Forged, Material Grade/Class Not Graded, Material Quality Standards ASTM A105, Pack Size Small Pack
