Oscilloscope, 2-channel, 100 MHz (Discontinued)
- Mfr # DSOX2012A
- Zoro # G3628685
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
DSOX2012A
Zoro #
G3628685
UPC #
013088355788
Country of Origin
Malaysia
Dimensions
Memory Size
100kpts/channel
Bandwidth (MHz)
100MHz
Manufacturers Warranty Length
3 yr
Real Time Bandwidth (MHz)
100MHz
Digital Storage Bandwidth
64M Internal, USB Stick Limit For External Storage
Details
Item
Oscilloscope
Type
Bench
Includes
1 Passive Probe Per Analog Channel
Vertical Resolution
10 bits
Max. Voltage
400
Features
Analog Oscilloscope, Digital Timing Analyzer, Integrated Function Generator, Mask Testing and Segmented Memory. FFT, Automatic Measurements
Display
8.5 inch WVGA
Sampling Rate
2 GSa/s Per Channel
Sweep Magnification
+-8 Divisions From Center Screen
Horizontal Resolution
2.5 pS
Triggering Source
Analog channels, External, Line WaveGen
Triggering Mode
Edge, Pulse Width, Pattern, Video
Rise Time
1.75 ns
Sweep Rate Real/Storage
2 ns/div to 50 s/div
Vertical Operating Modes
Normal, Peak Detect, Averaging, High Resolution, Segmented
Max./Min. Sweep Speed
2 nS/div to 50 s/div
Trigger Sensitivity Int./Ext.
10mV/div internal/ 200mV external
Sweep Speed Accuracy
25ppm +- 5 ppm Per Year Aging
Description
Oscilloscope, Bench, Bandwidth (MHz) 100MHz, Rise Time 1.75 ns, Max. Voltage 400, Max./Min. Sweep Speed 2 nS/div to 50 s/div, Trigger Sensitivity Int./Ext. 10mV/div internal/ 200mV external, Vertical Operating Modes Normal, Peak Detect, Averaging, High Resolution, Segmented, Sweep Speed Accuracy 25ppm +- 5 ppm Per Year Aging, +-8 Divisions From Center Screen Sweep Magnification, Triggering Mode Edge, Pulse Width, Pattern, Video, Triggering Source Analog channels, External, Line WaveGen
