Dorian Keyed Entry Lever

SmartKey with 6AL Latch and Round Corner Strike in Venetian Bronze
Delta LeverFeaturing SmartKeyA clean, streamlined design, Delta fits a whole range of decorating styles beautifully, from traditional to contemporary.Features:

• Featuring SmartKey Security
• ANSI/BHMA Grade 3 Certified Security
• ADA Compliant

Specifications: Door Prep:

• Cross Bore 2-1/8
• Edge bore 1

Backset:

• Adjustable 2-3/8 or 2-3/4
• UL functions 2-3/4 standard or
• 2-3/8 optional

Door Thickness:

• 1-3/8 - 1-3/4 Doors standard.

Cylinder:

• SmartKey Security or Traditional 5-pin Pin & Tumbler

Faceplates:

• 1 x 2-1/4 Specify round corner or square corner.
• Also available as drive-in latch.

Strikes:

• 2-1/4 Full lip standard.
• Specify round corner, square corner.
• Other options available.

Bolt:

• 1/2 Throw

ANSI/BHMA:

• A156.2 Grade 3
• all functions except 488

ADA:

• 200 function satisfies section 4.13.9 ADA requirements.

UL:

• Meets 3-hour fire rating for all UL specific functions.

Functions: Passage/Hall/Closet:

• Both levers always free

Privacy/Bed/Bath:

• Both levers locked or unlocked by turnbutton inside.
• Outside lever unlocked by emergency key

Keyed Entry Lever:

• Both sides locked or unlocked by key outside or turnbutton inside

Free Interior:

• Outside locked or unlocked by key outside or turn button inside. Inside always free.

Storeroom/Vestibule:

• Outside unlocked only while key is turned. Inside always free

Half Dummy Trim, Surface Mounted:

• For doors where only a pull is required. No operation

Finishes:

• Polished Brass - 3
• Antique Brass - 5
• Venetian Bronze - 11P
• Satin Nickel - 15
• Antique Nickel - 15A
• Polished Chrome - 26
• Satin Chrome - 26D

This product contains 1 cylinders per lock and is typically keyed alike in quantities of 3.
