SmartCode 917 Touchpad Electronic Lever

SmartKey with Round Corner Adjustable Latch and Round Corner Strike in Bright Chrome
SmartCode 917Residential Electronic LeverUnlock Your Home's Potential
Introducing the SmartCode 917 residential electronic lever. Combining the convenience of keyless entry with the highest residential security grade and the leading designs and finishes that will enhance any door in your home. Perfect for office doors, storage closets or interior garage doors, the SmartCode 917 delivers the right access solution to make your life more convenient, more stylish and more secure.Greater security for greater peace of mind
The SmartCode 917 residential electronic lever has been tested in three areas most important to homeowners like you: security, durability, and finish. It is BHMA certified AAA - the highest residential security rating available. It also features SmartKey Security to protect against advanced break-in techniques.Features:

• Highest residential security rating
• 3-year battery life
• Reversible lever to fit left-hand or right-hand doors
• Lock owner can switch between three different locking modes: Auto-lock, Passage, and Disable Passage

User Codes:

• Up to 30 user access codes
• Lock owner can program a one-time user code for emergencies, which deletes after first usage
• For added convenience, lock owners can program the lock from the outside with a programming code

Specifications: Function:

• Keyed entry electronic lever

Door Prep:

• Cross Bore 2- 1/8
• Edge Bore 1

Backset:

• 2 3/8 or 2 3/4

Door Thickness:

• 1 3/8 - 1 3/4

Faceplates:

• 1 x 2 1/4 round corner standard, drive in avaialbe

Strikes:

• 2 1/4 full lip round corner

Latch:

• Adjustable 2 3/8 x 2 3/4

Bolt:

• 1/2 throw, dead latch

Door Handing:

• Reversible for right or left-handed doors

Cylinder:

• SmartKey Security

UL Rating:

• 20 min

Temperature Range:

• Exterior: -40F to 150F
• Interior: 32F to 130F

Humidity:

• Exterior: - 100% condensing
• Interior: 30% 95% non-condensing

Easy Installation:

• Replaces existing door hardware with just a screwdriver
• No hard wiring needed
• Operates on a sing
