Shop LAPP

10-4C + 14-2C (BRAKE) VARIABLE, FREQUENCY DRIVE CABLE BLK, 1000FT

  • Mfr # 7410044

  • Zoro # G2846506

product price:
$
15.25
/ea
Sold in multiples of 25 for $381.25
Additional $7.20 delivery surcharge applies per item.
See details

Key Features

Jacket Color
Black
Jacket Material
Thermoplastic polymer
Insulation Material
Lapp Surge Guard
Conductor Material
Finely stranded tinned copper
Nominal Voltage
1000V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
7410044
Zoro #
G2846506
UPC #
-
Country of Origin
Unknown

Dimensions

# of Conductor Pairs - AWG Size #1
1
Minimum Bend Radius
7.5 x cable diameter
Bend Radius Installation Type
for stationary use
Thickness
0.9MM
Conductor Size/Gauge
COMPOSITE

Details

Jacket Color
Black
Jacket Material
Thermoplastic polymer
Insulation Material
Lapp Surge Guard
Conductor Material
Finely stranded tinned copper
Nominal Voltage
1000V
Shielding Cable
Shielding
Minimum Operating Temperature
-40°C
Operating Temperature Range
-25°C to +90°C
Cable Shielding Type/Material
Barrier tape; triple layer foil tape (100% coverage); tinned copper braid (85% coverage); foil shielded pairs
Conductor Pair #1 - Wire Gauge (AWG) / Conductor Cross-Section (mm2)
14 AWG (2.5 mm²)
Wire AWG #1 - # of Conductors
4
Maximum Operating Temperature
+105°C
Installation Type for Temperature Range
UL/CSA TC
Cable Construction (Wire Gauge & Conductor Count)
10 AWG/4C+(14 AWG/1Pr)
Conductor #1 - Wire Gauge (AWG) / Conductor Cross-Section (mm2)
10 AWG (6 mm²)
Ethernet Category
102
Conductor Stranding
Class 5 fine wire
Composite
Yes
Type
Stranded
Temperature Rating
125 Degrees Centigrade
Conductor Count
6 Conductor
Screen/Shield
Shielded
Voltage Range
600V
Product Type
Vfd
