No Product Image Available
Shop LEESON

Three-Phase General Purpose Motor, 2 HP, 56HC Frame, 575V Voltage, 3,450 Nameplate RPM

  • Mfr # 056T34F15674

  • Zoro # G411930269

product price:  $691.99
/ea
Free Shipping & Returns

Key Features

Nameplate RPM
3,450
Voltage
575V
Motor Mounting Type
Universal
Full Load Amps
2.5 A
Frame
56HC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
056T34F15674
Zoro #
G411930269
UPC #
691720115350
Country of Origin
Mexico

Dimensions

Length Less Shaft
11 11/16 in
Overall Length
13 9/16 in
Shaft Dia.
5/8 in
Shaft Length
1 7/8 in
Frame Size
56HC
Shaft Diameter
5/8 in
Wire Rope Length
13 9/16 in

Details

Item
General Purpose Motor
HP
2
Nameplate RPM
3,450
Voltage
575V
Motor Mounting Type
Universal
Full Load Amps
2.5 A
Frame
56HC
Motor Bearings
Ball
Motor Service Factor
1.15
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
RPM Range
3450
Phase
Three
No. of Speeds
1
Motor Application
General Purpose
Motor Shaft Rotation
Reversible
Voltage Compatibility
575 V
Hz
60 Hz
Ins. Class
F
Max. Ambient Temp.
40 Degrees C
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Shaft Design
Keyed
Nominal Efficiency
85.5 %
Standards
CE, CSA Certified, UL Listed
Weight
46 lb
NEMA Design
B
Usable @ 208V
Not Usable at 208V
Usable @ 200V
Not Usable at 200V
Motor Thermal Protection
None
Inverter Rated
Yes
Duty Cycle
Continuous
Inverter Rating
Inverter Rated
Bearing Type
Ball
Motor Enclosure Type
Totally Enclosed Fan Cooled
Application
General Purpose
Insulation Class
F
Shaft Design
Keyed
Ambient Temperature - Maximum
40 Degrees C
Efficiency Rating
Standard Efficiency (IE1)
Number of Speeds
1
Product Type
General Purpose Motor
Nameplate Service Factor @ 60 Hz
1.15
Frame Material
Steel
Frequency
60 Hz
NEMA Design Class
B
Mounting Position
All Angle
Full Load Current @ 60 Hz
2.5 A
Nameplate Voltage @ 50 Hz
190-220/380/415V AC
Nameplate RPM @ 50 Hz
1,465 RPM

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 2 HP, Nameplate RPM 3,450, Frame 56HC, Voltage 575V, 60 Hz Hz, Three Phase, Full Load Amps 2.5 A, Universal Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Steel, Max. Ambient Temp. 40 Degrees C, Reversible Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, 3450, CE, CSA Certified, UL Listed
