Lennox Thermostat, Digital, 4-1/4"x5-1/8" 24Z12 - main

Thermostat, Digital, 4-1/4"x5-1/8"

  • Mfr # 24Z12

  • Zoro # G009439952

product price: $75.19
/ea
Free Shipping & Returns

Key Features

Voltage
24V AC
Dual Transformer Compatible
Yes
Control Type
Slide Switch
Key Pad Lockout
Yes
Temperature Limiting
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
24Z12
Zoro #
G009439952
UPC #
-
Country of Origin
United States

Dimensions

Overall Width
5 1/8 in
Overall Depth
1 in
Overall Height
4 1/4 in
Digit Size
Standard

Details

Item
Thermostat
Voltage
24V AC
Dual Transformer Compatible
Yes
Control Type
Slide Switch
Key Pad Lockout
Yes
Temperature Limiting
Yes
Terminal Designations
B, C, G, O, Rc, Rh, W1, Y1
Humidification Control
No
Dehumidification Control
No
Display Type
Digital
Includes
(2) AA Batteries, Mounting Screws W Anchors
Stages
1H/1C Conventional, 1H/1C Heat Pump
Compatible System Type
2-Wire Hydronic Zone Systems
Backlit Screen Color
Blue
Application
Heat and Cool
Number of Heating Stages - Heat Pump System
1
Number of Cooling Stages - Conventional System
1
Number of Heating Stages - Conventional System
1
Programming Capability
Not Programmable
Number of Cooling Stages - Heat Pump System
1
System Settings
Cool-Heat-Off
Differential Type
Adjustable
Electrical Connection Type
Battery, Hardwired
System/Fan Settings
Cool-Heat-Off/Auto-On
Mounting Direction
Horizontal
Thermostat Type
Low Voltage
Minimum Control Temperature
45 Degrees F
Shape
Rectangle
Filter Change Reminder
Yes
Changeover Type
Manual
Housing Color
White
Number of Zones
1
Backlit Type
Touch Activated
Includes Positive Off
Yes
Maximum Control Temperature
90 Degrees F
Battery Type
(2) AA Batteries
Temperature Scale
Fahrenheit/Celsius
Millivolt Compatible
Yes
Mounting Direction/Shape
Horizontal
Amperage
3A
Contact Rating
24 V AC
Housing Material
Plastic
Fan Settings
Auto-On
Temperature Sensitivity
+/-1.5 Degrees F
Temperature Differential
+/- 1 Degrees F

Description

Thermostat, Heat and Cool, Manual, Compatible System Type 2-Wire Hydronic Zone Systems, Slide Switch, Dehumidification Control No, Differential Type Adjustable, Digit Size Standard, Digital, Dual Transformer Compatible Yes, Fan Settings Auto-On, Humidification Control No, Includes Positive Off Yes, Minimum Control Temperature 45 Degrees F, Maximum Control Temperature 90 Degrees F
