Leviton Duplex Outlet, Gray 15A 250V LNR96-6 - main

Duplex Outlet, Gray 15A 250V

  • Mfr # LNR96-6

  • Zoro # G922728706

product price:  $156.99
/ea
Free Shipping & Returns

Key Features

Mount Hole Center-to-Center Height
3.75 in
Contact Material
Nickel-Plated Brass
Number of Wires
3
Grounding
Grounded
Horsepower Rating
1/2 hp
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LNR96-6
Zoro #
G922728706
UPC #
-
Country of Origin
Mexico

Dimensions

Mount Hole Center-to-Center Height
3.75 in
Face Plate Height
4.46 in
Minimum Wire Size
18 AWG
Face Diameter
1.43 in
Face Plate Width
2.95 in
Maximum Wire Size
10 AWG

Details

Contact Material
Nickel-Plated Brass
Number of Wires
3
Grounding
Grounded
Horsepower Rating
1/2 hp
Market
Industrial
Current Rating
15 A
Number of Gangs
1
Voltage Rating
250V AC
Maximum Operating Temperature
60 Degrees C
Resistance Properties
Weather Resistant
NEMA Receptacle Configuration
L6-15R
NEMA Enclosure Rating
Not Rated
Phase
Single
Midget Locking
No
Shrouded
Yes
Features
Cover Cannot Be Lost or Left Off, Industry-Exclusive Self-Closing Cover Automatically Seals Receptacle When Not in Use, Mounts to Common FS/FD Cast Device Boxes, The Only Submersible Receptacle in Its Class, Wire Pigtails Make Installation Faster and Easier
Housing Color
Gray
IP Rating
Not Rated
Connection Orientation
Straight
Housing Material
Aluminum
Wire Connection Type
Screw Terminals
Item
Locking Receptacle
Number of Poles
2
Flange Type
Non-Flanged
Number of Outlets
1
Minimum Operating Temperature
-40 Degrees C
Standards
ANSI C-73, CSA C22.2 No. 42, NEMA WD-6, NOM-ANCE, UL 498
Cover Type
No Cover
Series
Insulgrip
For Environment
Wet
Hub Type
Dead End

Description

Locking Receptacle, Connection Orientation Straight, Current Rating 15 A, Flange Shape Not Applicable, Flange Type Non-Flanged, Housing Color Gray, Housing Material Aluminum, Mount Type Not Applicable, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration L6-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Shrouded Yes, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Hinged, Contact Material Nickel-Plated Brass, Cover Type No Cover
