Leviton Duplex Outlet, Gray 15A 250V LNR96-7 - main

Duplex Outlet, Gray 15A 250V

  • Mfr # LNR96-7

  • Zoro # G222728857

product price:  $164.99
/ea
Free Shipping & Returns

Key Features

Connection Orientation
Straight
Phase
Single
Voltage Rating
250V AC
Housing Material
Aluminum
Number of Outlets
1
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LNR96-7
Zoro #
G222728857
UPC #
-
Country of Origin
Mexico

Dimensions

Face Plate Width
2.95 in
Face Plate Height
4.46 in
Mount Hole Center-to-Center Height
3.75 in
Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG
Face Diameter
1.43 in

Details

Connection Orientation
Straight
Phase
Single
Voltage Rating
250V AC
Housing Material
Aluminum
Number of Outlets
1
Flange Type
Non-Flanged
Number of Wires
3
Series
Insulgrip
Hub Type
Dead End
Horsepower Rating
1/2 hp
Midget Locking
No
Current Rating
15 A
Number of Poles
2
Features
Cover Cannot Be Lost or Left Off, Industry-Exclusive Self-Closing Cover Automatically Seals Receptacle When Not in Use, Mounts to Common FS/FD Cast Device Boxes, The Only Submersible Receptacle in Its Class, Wire Pigtails Make Installation Faster and Easier
Maximum Operating Temperature
60 Degrees C
Minimum Operating Temperature
-40 Degrees C
Number of Gangs
1
NEMA Enclosure Rating
Not Rated
Item
Locking Receptacle
Shrouded
Yes
Market
Industrial
Grounding
Grounded
Resistance Properties
Weather Resistant
Housing Color
Gray
NEMA Receptacle Configuration
L6-15R
Wire Connection Type
Screw Terminals
Cover Type
No Cover
Standards
ANSI C-73, CSA C22.2 No. 42, NEMA WD-6, NOM-ANCE, UL 498
Contact Material
Nickel-Plated Brass
IP Rating
Not Rated
For Environment
Wet

Description

Locking Receptacle, Connection Orientation Straight, Current Rating 15 A, Flange Shape Not Applicable, Flange Type Non-Flanged, Housing Color Gray, Housing Material Aluminum, Mount Type Not Applicable, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration L6-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Shrouded Yes, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Hinged, Contact Material Nickel-Plated Brass, Cover Type No Cover
