Shop LEVITON

Locking Receptacle, 50 A, 480V AC, Black

  • Mfr # CS8469

  • Zoro # G522586713

product price:  $168.99
/ea
Free Shipping & Returns

Key Features

Mount Hole Center-to-Center Height
3.75 in
Standards
ANSI C-73, CSA Certified, NEMA WD-1, NEMA WD-6, NOM 57, RoHS, UL
Maximum Operating Temperature
167 Degrees F
Shrouded
Yes
Face Plate Width
2.13 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CS8469
Zoro #
G522586713
UPC #
78477326251
Country of Origin
Mexico

Dimensions

Mount Hole Center-to-Center Height
3.75 in
Face Plate Width
2.13 in
Face Diameter
1.97 in
Maximum Wire Size
6 AWG
Overall Depth
3.16 in
Minimum Wire Size
10 AWG
Face Plate Height
2.69 in

Details

Standards
ANSI C-73, CSA Certified, NEMA WD-1, NEMA WD-6, NOM 57, RoHS, UL
Maximum Operating Temperature
167 Degrees F
Shrouded
Yes
Hub Type
Dead End
Resistance Properties
Corrosion Resistant
Market
Industrial
Connection Orientation
Straight
Current Rating
50 A
Cover Type
No Cover
NEMA Receptacle Configuration
Non-NEMA
Housing Color
Black
Flange Type
Non-Flanged
For Environment
Industrial
Wire Connection Type
Screw Terminals
Midget Locking
No
Number of Gangs
1
Number of Poles
2
Phase
Single
Horsepower Rating
75 hp
UL 94 Flammability Rating
V-0
Housing Material
Nylon
Minimum Operating Temperature
-40 Degrees F
Mount Type
Flush
Series
Valise
Voltage Rating
480V AC
Number of Outlets
1
NEMA Enclosure Rating
Not Rated
Item
Locking Receptacle
Contact Material
Brass
Grounding
Grounded
Features
Extended Life Reduces Equipment Downtime, Premium Materials for Rugged Construction, Reduced Downtime Reduces Labor Costs and Increases Profits, Rugged Construction Extends Device Life
IP Rating
Not Rated
Number of Wires
3

Description

Locking Receptacle, Connection Orientation Straight, Current Rating 50 A, Flange Shape Not Applicable, Flange Type Non-Flanged, Housing Color Black, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration Non-NEMA, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Shrouded Yes, Voltage Rating 480V AC, Wire Connection Type Screw Terminals, Wiring Style Hinged, Contact Material Brass, Cover Type No Cover, Face Diameter 1.97 in
