Shop LEVITON

Outlet Strip, Surge, Rack Mounted, 2 5-20R, 5-20P, 15 ft., White

  • Mfr # 5302M-2S5

  • Zoro # G604186770

product price:  $134.99
/ea
Free Shipping & Returns

Key Features

Type
Surge, Rack Mounted
Total Number of Outlets
2
Receptacle Configuration
5-20R
Plug Configuration
5-20P
Color
White
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
5302M-2S5
Zoro #
G604186770
UPC #
078477611784
Country of Origin
Mexico

Dimensions

Cord Length
15 ft.
Length
10 3/4 in
Width
2 19/32 in
Height
1 21/32 in
Outlet Strip Length
10 13/16 in
Wire Size
14 AWG

Details

Item
Outlet Strip
Type
Surge, Rack Mounted
Total Number of Outlets
2
Number of Outlets
2
Receptacle Configuration
5-20R
Plug Configuration
5-20P
Color
White
Gauge/Conductor
12/3
Standards
ANSI/IEEE: Category A, NFPA: NFPA 99 2012 ed, UL 1363A and CSA C22.2: No. 21, UL 1449 3rd Ed and CSA C22.2: No. 8, UL 60601-1 and CSA C22.2: No.60601-1, UL 60950-1 and CSA C22.2: No. 60950-1
Rated Joules
644
Trade Designation
SJT
Medical Facility Use
Outside Patient Care Areas (UL 1449); Patient Care - Only When Permanently Mounted (UL 1363A); Patient Care (UL 60601-1)
Noise Attenuation
6dB to -29dB (100kHz to 100MHz)
Mounting Style
Screw
Hz
60 Hz Hz
Voltage
125V AC
Surge Protection Indicator
Yes
Application
Medical
Housing Material
Metal
Special Features
Special Purpose Relocatable Power Tap (SPRPT)
Max. Surge Current
27 kA
Power Indicator
Yes
Max. Amps
20 A
For Use With
Isolated Power Systems
Operating Temperature
0°C to 40°C
Number of Receptacles
2
Frequency
60 Hz
Noise Filtering
-6dB to -29dB (100kHz to 100MHz)
UL 1363A & CSA C22.2
No. 21
Surge Protection
Yes
Outlet Covers
Polypropylene
Grade
Medical
UL 60950-1 & CSA C22.2
No. 60950-1
Joules Rating
644J
Voltage Protection Rating (VPR) L-N, L-G, N-G
600V, 600V, 500V
HG Outlet Configuration
NEMA 5-20R
Line Cord
#14/3 SJT
Enclosure
Powder Coated Steel
Maximum Leakage Current
<100µA
Maximum Surge Current, Per Mode (L-N)
27kA
Product Type
Outlet Strip
Number of Conductors
3
NEMA Receptacle Configuration
5-20R
Maximum Surge Current
27 kA
Rated Energy Absorption
644 J
NEMA Plug Configuration
5-15P
Includes
Locking Cover
Communication Port
None
Plug Style
Straight
Maximum Current
20 A
Medical Facility Use UL Rating
UL 1363A, UL 1449, UL 60601-1

Description

Outlet Strip, Application Medical, Housing Material Metal, Total Number of Outlets 2, Max. Amps 20 A, Cord Length 15 ft, Number of Power Switches 0, Power Indicator Yes, Number of Outlet Rows 2, Receptacle Configuration Hospital Grade, Plug Configuration NEMA 5-20P, Wire Size 14 AWG, Mounting Style Screw, Color White, Medical Facility Use Outside Patient Care Areas (UL 1449); Patient Care - Only When Permanently Mounted (UL 1363A); Patient Care (UL 60601-1), Number of Transformer Outlets 0
