Plugs and Receptacles
Mfr # 16R19-UH
Zoro # G122587769
product price:Â
$
48.85
/ea
Key Features
Mounting Style
Through Hole Mounting
Housing Color
Brown
Overall Length
3.72 in
Terminal Connection Type
Half Round with Tapped Hole
Flange Height
2.28 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 16R19-UH
- Zoro #
- G122587769
- UPC #
- 78477857991
- Country of Origin
- Mexico
- Mounting Style
- Through Hole Mounting
- Housing Color
- Brown
- Terminal Connection Type
- Half Round with Tapped Hole
- Housing Material
- Nylon
- Item
- Single Pole Receptacle
- NEMA Enclosure Rating
- 3R
- Standards
- CSA, UL
- Voltage Rating
- 600V AC, 600V DC
- Contact Material
- Brass
- Minimum Operating Temperature
- -40 Degrees F
- Flange Shape
- Square
- Connection Orientation
- Straight
- Gender
- Male
- Current Rating
- 400 A
- Series
- 16
- Maximum Operating Temperature
- 185 Degrees F
- End Type
- Taper Nose
- For Location
- Outdoor
- Resistance Properties
- Chemical Resistant, UV/Sunlight Resistant
Description
Single Pole Receptacle, Connection Orientation Straight, Current Rating 400 A, Gender Male, Housing Color Brown, Housing Material Nylon, Maximum Wire Size 4/0 AWG, Minimum Wire Size 2 AWG, Voltage Rating 600V AC, 600V DC, Contact Material Brass, End Type Taper Nose, Flange Height 2.28 in, Flange Shape Square, Flange Width 2.28 in, NEMA Enclosure Rating 3R, Standards CSA, UL, Terminal Connection Type Half Round with Tapped Hole, For Location Outdoor, Maximum Operating Temperature 185 Degrees F
