Plugs and Receptacles
Mfr # 16R20-UW
Zoro # G822587526
product price:Â
$
46.35
/ea
Key Features
Current Rating
400 A
Connection Orientation
Straight
Mounting Style
Through Hole Mounting
Minimum Operating Temperature
-40 Degrees F
Housing Color
White
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 16R20-UW
- Zoro #
- G822587526
- UPC #
- 78477716687
- Country of Origin
- Mexico
- Current Rating
- 400 A
- Connection Orientation
- Straight
- Mounting Style
- Through Hole Mounting
- Minimum Operating Temperature
- -40 Degrees F
- Housing Color
- White
- Resistance Properties
- Chemical Resistant, UV/Sunlight Resistant
- NEMA Enclosure Rating
- 3R
- Gender
- Female
- Voltage Rating
- 600V AC, 600V DC
- Housing Material
- Nylon
- Series
- 16
- Terminal Connection Type
- Half Round with Tapped Hole
- Contact Material
- Brass
- Maximum Operating Temperature
- 185 Degrees F
- Standards
- CSA, UL
- End Type
- Taper Nose
- Flange Shape
- Square
- For Location
- Outdoor
- Item
- Single Pole Receptacle
Description
Single Pole Receptacle, Connection Orientation Straight, Current Rating 400 A, Gender Female, Housing Color White, Housing Material Nylon, Maximum Wire Size 4/0 AWG, Minimum Wire Size 2 AWG, Voltage Rating 600V AC, 600V DC, Contact Material Brass, End Type Taper Nose, Flange Height 2.28 in, Flange Shape Square, Flange Width 2.28 in, NEMA Enclosure Rating 3R, Standards CSA, UL, Terminal Connection Type Half Round with Tapped Hole, For Location Outdoor, Maximum Operating Temperature 185 Degrees F
