Shop LEVITON

Plugs and Receptacles

  • Mfr # MDS3-AST
  • Zoro # G522587086
product price:
$
732.99
/ea
Free Shipping & Returns

Key Features

Number of Locks
0
Standards
CE, cULus, IEC, NEMA, NOM, NSF
Housing Material
Stainless Steel
Depth
6 in
NEMA Enclosure Rating
12, 13, 3R, 4X
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
MDS3-AST
Zoro #
G522587086
UPC #
78477723487
Country of Origin
Mexico
Number of Locks
0
Standards
CE, cULus, IEC, NEMA, NOM, NSF
Housing Material
Stainless Steel
NEMA Enclosure Rating
12, 13, 3R, 4X
Neutral Assembly Included
Yes
Handle Color
Red
Horsepower @ 240V AC
10 hp
Number of Wires
8
Contact Form
3PST
Features
On/Off Indicator
Current Rating
30 A
Horsepower @ 480V AC
20 hp
Number of Poles
1
Phase
Single or Three
Horsepower @ 600V AC
25 hp
Protection Method
Non-Fusible
Series
Powerswitch
Item
Disconnect Switch
IP Rating
IP66; IP67; IP68; IP69K
Voltage
600V AC
Mounting Style
Surface Mount; Wall Mount
Duty
Heavy Duty
Resistance Properties
Dust-Tight, High Temperature Washdown, Submersible, Suitable for High Pressure, UV Resistant, Watertight
For Fuse Class
Class J
Environment
Indoor/Outdoor
UL 508 Certification
Yes

Description

Disconnect Switch, Contact Form 3PST, Current Rating 30 A, Depth 6 in, Duty Heavy Duty, Environment Indoor/Outdoor, Features On/Off Indicator, For Fuse Class Class J, Handle Color Red, Height 9 in, Horsepower @ 240V AC 10 hp, Horsepower @ 480V AC 20 hp, Horsepower @ 600V AC 25 hp, Housing Material Stainless Steel, IP Rating IP66; IP67; IP68; IP69K, Mounting Style Surface Mount; Wall Mount, NEMA Enclosure Rating 12, 13, 3R, 4X, Neutral Assembly Included Yes, Number of Locks 0
