  9. Straight Blade Plug, 15 A, 125V AC
Leviton Straight Blade Plug, 15 A, 125V AC LNR80-1E - main

Straight Blade Plug, 15 A, 125V AC

  • Mfr # LNR80-1E

  • Zoro # G716091313

product price: $50.15
/ea

Key Features

Overall Length
2.98 in
Connection Orientation
Straight
NEMA Enclosure Rating
12, 13, 3R, 4, 4X, 6, 6P
Voltage Rating
125V AC
Market
Industrial
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LNR80-1E
Zoro #
G716091313
UPC #
078477692646
Country of Origin
United States

Dimensions

Overall Length
2.98 in
Face Diameter
2.62 in
Outside Diameter
2.62 in
Body Length
2.25 in
Maximum Wire Size
10 AWG
Minimum Wire Size
18 AWG

Details

Item
Straight Blade Plug
Connection Orientation
Straight
NEMA Enclosure Rating
12, 13, 3R, 4, 4X, 6, 6P
Voltage Rating
125V AC
Market
Industrial
Housing Color
Black
IP Rating
IP66, IP67, IP68, IP69K
Resistance Properties
Corrosion Resistant
Housing Material
Nylon
Blade Material
Brass
Wire Connection Type
Screw Terminals
Grounding
Grounded
For Environment
Wet
Number of Blades
3
Number of Poles
2
Current Rating
15 A
Minimum Operating Temperature
-40 Degrees C
NEMA Plug Configuration
5-15P
Maximum Operating Temperature
60 Degrees C
Standards
ANSI C-73, CSA C22.2 No. 42, NEMA WD-6, NOM-ANCE, UL 498
Phase
Single
Polarized
No
Wiring Style
Standard

Description

Plug, Straight Blade,Industrial Grade
