  11. Straight Blade Receptacle, 14-20R, 20 A, 125/250V AC, 3 Pole, 4 Wire, Flush Mount, Grounded
Leviton Straight Blade Receptacle, 14-20R, 20 A, 125/250V AC, 3 Pole, 4 Wire, Flush Mount, Grounded 8410 - main

Straight Blade Receptacle, 14-20R, 20 A, 125/250V AC, 3 Pole, 4 Wire, Flush Mount, Grounded

  • Mfr # 8410

  • Zoro # G704256014

product price: $58.29
/ea

Key Features

Receptacle Type
Single
NEMA Receptacle Configuration
14-20R
Current Rating
20 A
Voltage Rating
125/250V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8410
Zoro #
G704256014
UPC #
07847744064
Country of Origin
Mexico

Details

Item
Straight Blade Receptacle
Receptacle Type
Single
NEMA Receptacle Configuration
14-20R
Current Rating
20 A
Voltage Rating
125/250V AC
Phase
Single
Number of Poles
3
Number of Wires
4
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Black
Mount Type
Flush
IP Rating
Not Rated
Standards
UL Listed
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Wiring Method - Plugs and Receptacles
Back and Side
Outlet Type - Plugs and Receptacles
Single
Number of Gangs
1
Sub-Category
Single Receptacles
Application Environment
Commercial
Material
Phenolic (Body)
NEMA Receptacle Configuration - Plugs and Receptacles
14-20R
Hub Type
Dead End
Surge Protection
No
Grade
General Use
Shrouded
No
AFCI
No
UL 94 Flammability Rating
V-2
Number of Outlets
1
Polarized
Yes
Housing Material
Phenolic
GFCI
No
Connection Orientation
Straight
Cover Type
No Cover
NEMA Enclosure Rating
Not Rated
Flange Shape
Rectangular
Market
Commercial
Standards and Certifications
UL
Strap Material
Steel
Body Material
Phenolic
Pole
3
Termination
Back & Side
Wire
4
Screw Terminal Torque
14-18 in-lbs

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Black, Housing Material Phenolic, Mount Type Recessed, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 14-20R, Number of Gangs 1, Number of Poles 3, Number of Wires 4, Phase Single, Polarized Yes, Receptacle Type Single, Resistance Properties Tamper Resistant, Standards UL Listed

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
