  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown 8200 - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Brown

  • Mfr # 8200

  • Zoro # G604393192

product price: $10.39
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8200
Zoro #
G604393192
UPC #
07847781634
Country of Origin
Mexico

Dimensions

Overall Depth
0.9 in
Face Plate Width
1.5 in
Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Brown
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42 File E152105, NEMA WD-6, NOM 057 Certified, UL 498 File E13399, UL Federal Specification WC-596 File E13399
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Application Environment
Extra Heavy-Duty Hospital Grade
Material
Nylon (Body and Face)
Sub-Category
Duplex Receptacles
Outlet Type - Plugs and Receptacles
Duplex
HP
1/2 hp
Polarized
Yes
Horsepower Rating
1/2 hp
UL 94 Flammability Rating
V-2
Grade
Hospital Grade Fed. Spec.
Maximum Operating Temperature
140 Degrees F
NEMA Enclosure Rating
Not Rated
Includes Mounting Hardware
Yes
Cover Type
No Cover
Housing Material
Nylon
Contact Material
Nickel-Plated Brass
Number of Outlets
2
Minimum Operating Temperature
-40 Degrees F
GFCI
No
Connection Orientation
Straight
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Grounding Screw
Plated Brass
Termination
Back or Side Wire
Ground Clips
Nickel-Plated Brass
UL Fed Spec WC-596
File E13399
Clamp Nuts
Zinc-Plated Steel
CSA C22.2 No. 42
File 152105
Device Type
Duplex Receptacle Outlet
Yoke
Nickel-Plated Brass
Torque Range
14-16 inch pounds
Operating Temperature
-40°C to 60°C
Strap Material
Nickel Plated Brass
Dielectric Voltage
Withstands 2000V per UL498
Line Contacts
Nickel-Plated Brass Triple-Wipe .040 Thick
Current Limiting
Full Rated Current
UL498HG
File E13399
Screw Terminal Torque
14-18 in-lbs
Face Material
Nylon
Feature 4
Smooth Face
ANSI
C-73
Wire
3
Pole
2
Terminal Screws
Nickel-Plated Brass 10-32
Body Material
Nylon
Flammability
Rated V-2 per UL 94
Terminal Accom.
14-10 AWG

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Brown, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable
