  11. Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory AFTR1-I - main

Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # AFTR1-I

  • Zoro # G704393337

product price: $34.19
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
AFTR1-I
Zoro #
G704393337
UPC #
07847757493
Country of Origin
China

Dimensions

Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Ivory
Mount Type
Flush
Standards
ANSI C73, CSA C22.2 No. 42, NOM 057, UL 498, UL Federal Specification WC-596, UL1699.A
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Surge Suppression
Yes
Application Environment
General Purpose
Weather Resistant - Plugs and Receptacles
No
HP
1 hp
Power Indicator
Yes
Special Features
Device Design Reduces Nuisance Tripping, Impact-Resistant, Over-Voltage Resistant, Silver Alloy Contact, Two-Year Product Warranty
Includes
Screws, Self Grounding Clip
Outlet Type - Plugs and Receptacles
Blank Face
Tamper Resistant
Yes
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Wiring Method - Plugs and Receptacles
Back and Side
Self-Testing
No
Cover Type
No Cover
Surge Protection
No
Reset Type
Automatic
AFCI
Yes
Reverse Service
Yes
Grade
General Use
Compatible with Series
AFTR1
Housing Material
Polycarbonate
GFCI
No
Self Testing
No
Connection Orientation
Straight
Maximum Operating Temperature
150.8 Degrees F
Minimum Operating Temperature
-31 Degrees F
Number of Outlets
2
Polarized
Yes
Hub Type
Feed Through
Visual Indicator Lights
Power Connected
Horsepower Rating
1 hp
UL 94 Flammability Rating
V-2
Contact Material
Brass
Wall Plate Material
Nylon
CSA Technical Information Letter No. M-02A
Yes
Terminal Screws
Plated Steel
Termination
Back & Side
Flammability
Rated V-2 per UL 94
Grounding Screw
Plated Steel
Terminal Accom.
14-10 AWG
UL1699.A
File E342815
Clamps
Brass
ANSI
C-73
Face Material
Thermoplastic
Torque Range
14 - 18 in.-lbs
CSA C22.2 No. 42
Yes
Series
AFTR1
At Rated Voltage
1 HP
Pole
2
UL498
Yes
Dielectric Voltage
Withstands 2000V per UL498
Body Material
Polycarbonate
Strap Material
Galvanized Steel
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Wire
3
Yoke
Zinc-Plated Steel
Standards and Certifications
UL/CSA, NEMA WD6
UL Fed Spec WC-596
Yes
Wallplate
Included
Feature
Tamper-Resistant
Line Contacts
Brass Double-Wipe .031 Thick
Operating Temperature
-35C to +66C
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 15 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Polycarbonate, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Tamper Resistant
