  11. Straight Blade Receptacle, 5-15R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-15R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory T5380-I - main

Straight Blade Receptacle, 5-15R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # T5380-I

  • Zoro # G904393298

product price: $63.19
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
T5380-I
Zoro #
G904393298
UPC #
07847743437
Country of Origin
Mexico

Dimensions

Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
Ivory
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL 1449, UL 498
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Outlet Type - Plugs and Receptacles
Decorator Duplex
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Wiring Method - Plugs and Receptacles
Back and Side
Voltage
125 VAC
Material
Nylon (Face), Polycarbonate (Body)
Application Environment
Commercial
Tamper Resistant
Yes
Sub-Category
Duplex Receptacles
NEMA Configuration
5-20
Surge Suppression
Yes
Contact Material
Brass
Cover Type
No Cover
Number of Outlets
2
GFCI
No
Grade
General Use
Key Resistance Properties
Tamper Resistant
Number of Poles & Wires
2 Pole / 3 Wire
Includes Mounting Hardware
Yes
NEMA Enclosure Rating
Not Rated
Polarized
Yes
Maximum Operating Temperature
140 Degrees F
Wire Connection Types
Screw Terminals
Connection Orientation
Straight
Additional Electrical Protection
Surge Protection
Market
Commercial, Industrial, Residential
Surge Protection
Yes
Maximum Surge Current
27 kA
Minimum Operating Temperature
-40 Degrees F
Housing Material
Polycarbonate
Feature
Tamper-Resistant
Device Type
Duplex Receptacle Outlet
Terminal Screws
Brass-Plated Steel
Agency Certifications
UL 498, UL 1449 3rd Edition Listed and CSA C22.2 Certified Type 3
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
ANSI
C-73
Grounding Screw
Brass-Plated Steel
Current Limiting
Full Rated Current
Yoke
Zinc-Plated Steel
Maximum Surge Current, Per Mode (Per Phase)
27kA (L-N:18kA, L-G:9kA)
MCOV
150V rms
Noise Rejection
-30dB at 500kHz-30MHz
Clamp Nuts
Zinc-Plated Steel
Torque Range
14-16 inch pounds
Short Circuit Current Rating
5kA
Termination
Back or Side Wire
Function
Surge Protective
Ground Clips
Brass-Plated Steel
Pole
2
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Wire
3
Joules Rating
720
Body Material
Polycarbonate
Dielectric Voltage
Withstands 2000V per UL498
Diagnostics
Indicator Light
Nominal Discharge Current Rating
3kA
Screw Terminal Torque
14-18 in-lbs
Face Material
Nylon
Operating Temperature
-40°C to 60°C
Shutter Mechanism
Delrin® Acetal
Terminal Accom.
14-10 AWG
Line Contacts
Brass Triple-Wipe

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Polycarbonate, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Tamper Resistant

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
