  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray 5362-IGG - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Gray

  • Mfr # 5362-IGG

  • Zoro # G904393199

product price: $8.49
/ea
Sold in multiples of 10 for $84.90

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
5362-IGG
Zoro #
G904393199
UPC #
07847705328
Country of Origin
Mexico

Dimensions

Face Plate Width
1.3 in
Mount Hole Center-to-Center Height
3.3 in
Minimum Wire Size
14 AWG
Face Plate Height
2.8 in
Maximum Wire Size
10 AWG
Overall Depth
1.1 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Isolated Ground
Housing Color
Gray
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL 498, UL Federal Specification WC-596
Flange Type
Non-Flanged
Sub-Category
Duplex Receptacles
Application Environment
Heavy-Duty Industrial Grade
Outlet Type - Plugs and Receptacles
Duplex
Material
Thermoplastic Nylon (Body and Face)
Voltage
125 VAC
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
HP
1 hp
Includes Mounting Hardware
Yes
Connection Orientation
Straight
Number of Outlets
2
Minimum Operating Temperature
-40 Degrees F
Contact Material
Phosphor Bronze
Horsepower Rating
1 hp
Market
Commercial, Industrial
Maximum Operating Temperature
140 Degrees F
NEMA Enclosure Rating
Not Rated
Cover Type
No Cover
Grade
Federal Specification
Polarized
Yes
GFCI
No
UL 94 Flammability Rating
V-2
Housing Material
Thermoplastic Nylon
Terminal Accom.
14-10 AWG
Terminal Screws
Plated Brass
Face Material
Thermoplastic Nylon
Wire
3
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Dielectric Voltage
Withstands 2000V per UL498
Clamp Nuts
Galvanized Steel
CSA C22.2 No. 42
File 152105
Strap Material
Galvanized Steel
UL498
File E13399
At Rated Voltage
1 HP
Isolated Ground System
Brass
Pole
2
Body Material
Thermoplastic Nylon
Feature 4
Smooth Face
Operating Temperature
-40°C to 60°C
Screw Terminal Torque
14-18 in-lbs
Termination
Back or Side Wire
Current Limiting
Full Rated Current
Device Type
Duplex Receptacle Outlet
UL Fed Spec WC-596
File E13399
ANSI
C-73
Line Contacts
Phosphor Bronze
Flammability
Rated V-2 per UL 94
Grounding Screw
Brass 8-32
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Torque Range
14-16 inch pounds

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Isolated Ground, Hazardous Location Specification Not Applicable, Housing Color Gray, Housing Material Thermoplastic Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable
