  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory 7380-I - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # 7380-I

  • Zoro # G604393284

product price: $69.49
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
7380-I
Zoro #
G604393284
UPC #
07847710226
Country of Origin
Mexico

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
14 AWG

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Ivory
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 Certified Type 3, NEMA WD-6, NOM 057, UL 498 UL 1449 3rd Edition Listed
Flange Type
Non-Flanged
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Wiring Method - Plugs and Receptacles
Back and Side
Outlet Type - Plugs and Receptacles
Decorator Duplex
Application Environment
Commercial
HP
1 hp
Sub-Category
Duplex Receptacles
Surge Suppression
Yes
Material
Thermoplastic Nylon (Body and Face)
Polarized
Yes
Number of Outlets
2
Horsepower Rating
1 hp
UL 94 Flammability Rating
V-2
Connection Orientation
Straight
Housing Material
Thermoplastic Nylon
GFCI
No
Contact Material
Brass
Market
Commercial, Industrial, Residential
Maximum Operating Temperature
140 Degrees F
Surge Protection
Yes
Minimum Operating Temperature
-40 Degrees F
Grade
General Use
Cover Type
No Cover
NEMA Enclosure Rating
Not Rated

Description

Receptacle, Connection Orientation Straight, Cover Type Screw-On Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Not Applicable
