  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory M8300-ILI - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, Ivory

  • Mfr # M8300-ILI

  • Zoro # G604393277

product price: $29.19
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
M8300-ILI
Zoro #
G604393277
UPC #
07847754361
Country of Origin
Mexico

Dimensions

Mount Hole Center-to-Center Height
3.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Snap In Module
Grounding
Self-Grounded
Housing Color
Ivory
Mount Type
Flush
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, UL 498, UL Federal Specification WC-596
Flange Type
Non-Flanged
Sub-Category
Duplex Receptacles
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Includes
Wallplate
Outlet Type - Plugs and Receptacles
Duplex
Application Environment
Extra Heavy-Duty Hospital Grade
Material
Nylon (Body and Face)
HP
1 hp
Wiring Method - Plugs and Receptacles
Modular
Special Features
Illuminated
NEMA Enclosure Rating
Not Rated
Grade
Hospital Grade
Cover Type
No Cover
Contact Material
Brass
Number of Outlets
2
Housing Material
Nylon
Horsepower Rating
1 hp
GFCI
No
Minimum Operating Temperature
-40 Degrees F
Connection Orientation
Straight
Maximum Operating Temperature
140 Degrees F
Includes Mounting Hardware
Yes
Polarized
Yes
Operating Temperature
-40°C to 60°C
Feature 4
Smooth Face
Body Material
Nylon
UL 498 & Fed Spec WD496
E13399
Line Contacts
0.040" Brass
Wire
3
CSA
152105
Pole
2
Strap Material
Nickel Plated Brass
Current Limiting
Full Rated Current
Lead Identification
Leads identified in accordance with UL 498 (black, white & green)
Face Material
Nylon
Shutter Mechanism
Delrin® Acetal
Dielectric Voltage
Withstands 2000V per UL498
Device Type
Duplex Receptacle Outlet
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Locking Pins
Solid Brass
Feature 3
Illuminated
ANSI
C-73
Termination
Modular
Illumination
100,000 HR Green LED's
Ground Clips
Brass
Flammability
Rated V-2 per UL94

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Ivory, Housing Material Nylon, Mount Type Flush, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Duplex, Resistance Properties Not Applicable, Standards ANSI, cULus Listed, NOM Certified, RoHS Compliant
