Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Single, White

  • Mfr # AFTR2-W
  • Zoro # G404393361
product price:
$
36.55
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
AFTR2-W
Zoro #
G404393361
UPC #
07847757498
Country of Origin
China

Dimensions

Minimum Wire Size
14 AWG
Maximum Wire Size
10 AWG
Mount Hole Center-to-Center Height
3.4 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Self-Grounded
Housing Color
White
Mount Type
Flush
Standards
ANSI C73, CSA C22.2 No. 42, NOM 057, UL 498, UL Federal Specification WC-596, UL1699.A
Resistance Properties
Tamper Resistant
Flange Type
Non-Flanged
Outlet Type - Plugs and Receptacles
Blank Face
Surge Suppression
Yes
Weather Resistant - Plugs and Receptacles
No
Tamper Resistant
Yes
HP
1 hp
Includes
Screws, Self Grounding Clip
Application Environment
General Purpose
Wiring Method - Plugs and Receptacles
Back and Side
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Special Features
Device Design Reduces Nuisance Tripping, Impact-Resistant, Over-Voltage Resistant, Silver Alloy Contact, Two-Year Product Warranty
Power Indicator
Yes
Self-Testing
No
Cover Type
No Cover
Reset Type
Automatic
UL 94 Flammability Rating
V-2
Horsepower Rating
1 hp
Reverse Service
Yes
Polarized
Yes
AFCI
Yes
Maximum Operating Temperature
150.8 Degrees F
Compatible with Series
AFTR2
Self Testing
No
Minimum Operating Temperature
-31 Degrees F
Housing Material
Polycarbonate
Contact Material
Brass
Number of Outlets
2
Wall Plate Material
Nylon
Visual Indicator Lights
Power Connected
Surge Protection
No
Connection Orientation
Straight
Grade
General Use
GFCI
No
Body Material
Polycarbonate
Operating Temperature
-35C to +66C
Terminal Screws
Plated Steel
Feature
Tamper-Resistant
Wire
3
Dielectric Voltage
Withstands 1250VAC per UL 1699A
UL 498
Yes
Pole
2
At Rated Voltage
1 HP
CSA Technical Information Letter No. M-02A
Yes
Series
AFTR2
Flammability
Rated V-2 per UL 94
Terminal Accom.
14-10 AWG
CSA C22.2 No. 42
Yes
Strap Material
Galvanized Steel
UL Fed Spec WC-596
Yes
Clamps
Brass
Face Material
Thermoplastic
ANSI
C-73
Wallplate
Included
Standards and Certifications
UL/CSA, NEMA WD6, NEMA WD1
Temperature Rise
Max 30C after 250 cycles OL at 200 percent rated current
Grounding Screw
Plated Steel
Termination
Back & Side
UL1699.A
File E342815
Yoke
Zinc-Plated Steel
Torque Range
14 - 18 in.-lbs
Line Contacts
Brass Triple-Wipe
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
NEMA Enclosure Rating
Not Rated
IP Rating
Not Rated
Status Indicator Lights
Power Connected
Number of Wall Plates Included
0
Shrouded
No
Number of Gangs
1

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Housing Color White, Housing Material Polycarbonate, Mount Type Flush, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Decorator Duplex, Resistance Properties Tamper Resistant, Standards CSA Certified, NEMA WD-1, NEMA WD-6, UL Listed, Voltage Rating 125V AC, Wire Connection Type Screw Terminals
