  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, White
Leviton Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, White 21254-HW - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Single, White

  • Mfr # 21254-HW

  • Zoro # G204393301

product price: $36.69
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
21254-HW
Zoro #
G204393301
UPC #
07847783082
Country of Origin
Mexico

Dimensions

Mount Hole Center-to-Center Height
3.4 in
Minimum Wire Size
14 AWG
Maximum Wire Size
12 AWG
Face Plate Height
4.5 in
Face Plate Width
4.5 in
Overall Depth
1.2 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Side
Grounding
Grounded
Housing Color
White
Mount Type
Surface
IP Rating
Not Rated
Standards
ANSI C73, CSA C22.2 No. 42 File E152105, NEMA WD-1 and WD-6, UL 498 File E13399, UL 498HG File E13399
Flange Type
Non-Flanged
Sub-Category
Quad Receptacles
Outlet Type - Plugs and Receptacles
Quad
Wiring Method - Plugs and Receptacles
Side
Material
Nylon (Body and Face)
HP
1 hp
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Includes
Strap Material
Application Environment
Heavy-Duty Hospital Grade
GFCI
No
Number of Outlets
4
Includes Mounting Hardware
Yes
Minimum Operating Temperature
-40 Degrees F
NEMA Enclosure Rating
Not Rated
UL 94 Flammability Rating
V-2
Cover Type
No Cover
Contact Material
Phosphor Bronze
Maximum Operating Temperature
140 Degrees F
Grade
Hospital Grade
Housing Material
Nylon
Horsepower Rating
1 hp
Connection Orientation
Straight
Polarized
Yes
Current Limiting
Full Rated Current
Line Contacts
Phosphor Bronze
CSA C22.2 No. 42
File 152105
Strap Material
Galvanized Steel with Riveted Ground Contacts
Screw Terminal Torque
10-12 in-lbs
Flammability
Rated V-2 per UL 94
Torque Range
12-14 inch pounds
Face Material
Nylon
Grounding Screw
Plated Steel
Mounting Screws
Zinc-Plated Steel 8-32
Termination
Side Wire
Wire
3
Terminal Screws
Brass 8-32
UL498
File E13399
Operating Temperature
-40°C to 60°C
Body Material
Nylon
Temperature Rise
Max 30C after 50 cycles OL at 150 percent rated current
UL498HG
File E13399
Dielectric Voltage
Withstands 2000V per UL498
Device Type
Quadruplex Receptacle Outlet
ANSI
C-73
Pole
2
At Rated Voltage
1 HP
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
Terminal Accom.
14-12 AWG

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 20 A, GFCI No, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color White, Housing Material Nylon, Mount Type Surface, NEMA Enclosure Rating Not Rated, NEMA Receptacle Configuration 5-20R, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Quad, Resistance Properties Not Applicable
