  13. Toggle Switch 60A 600V 3P 3R Mtr Strt Sw
This item is Discontinued.
Leviton Toggle Switch 60A 600V 3P 3R Mtr Strt Sw N3603

Toggle Switch 60A 600V 3P 3R Mtr Strt Sw (Discontinued)

  • Mfr # N3603
  • Zoro # G3966664
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
N3603
Zoro #
G3966664
UPC #
78477101865
Country of Origin
Mexico

Dimensions

Height
6.12 in
Width
6.56 in
Length
8.81 in
Dimensions
8.1 in H x 6.3 in W x 4.3 in D

Details

Contact Form
TP
Voltage
600 VAC
Connection
Back Wired;Side Wired
Material
Powder Coated Steel
Color
Grey
Termination
Front
Dielectric Voltage
Withstands 2200V for 1 min.
Terminal Accom.
10-4 AWG
ANSI
C-73
Torque Range
25 inch pounds maximum
Temperature Rise
50ºC Max at full rated current
Yoke
Nickel-Plated Brass
Device Type
Enclosed Switch
Toggle
Thermoplastic Polyester
Terminal Screws
Zinc-Plated Steel, Triple Combination
Endurance
6,000 cycles inductive motor type load
Grounding
Non-Grounding
Handle Material
Valox 357 PBT
Contacts
.046" Thick Silver-Cadmium Oxide
Face Material
Thermoplastic Polyester
UL 60947-4-1
supersedes UL 508
Strap Material
Nickel Plated Brass
Enclosure Rating
Type 3R
Base Material
Thermoplastic Polyester
NEMA
WD-1 & WD-6
cUL per CSA C22.2 No. 111
File #E63969
HP Rating
10HP-240V 25HP-480V 30HP-600V
Enclosure Material
Powder-Coated Steel
Operating Temperature
-40°C to 60°C
Flammability
Rated V-0 per UL 94
Amperage
60 A
Terminal ID
T1, T2, T3, L1, L2 & L3 marked on back of device
Pole
3
Mounting Type
Threaded
Application
Commercial
Actuator
Toggle
Environmental Conditions
Flammability (Rated V-2 per UL94)
Action
TP
Enclosure Type
NEMA 3R
Type
Enclosure with Three-Pole AC Motor Starter Switch
Actuator Type
Toggle
Temperature Rating
-40 to 65 °C
Finish
Powder Coated
Standard
NEMA (WD-1 & WD-6);ANSI (C-73);NOM Certified (057);UL508 (File E63969);cUL per CSA C22.2 No. 111 (File E63969)
Terminal Type
Back/Side Wired
Horsepower
30 hp

Description

60 Amp, 600 Volt, Toggle In Type 3R Enclosure, Three-Pole, AC Motor Starting Switch, Suitable as Motor Disconnect, Industrial Grade, Black
