  11. Wall Mount Sensor, Occupancy, Photocell, Vacancy, Gray, 2,400 sq ft, Fluorescent, Incandescent, LED
Leviton Wall Mount Sensor, Occupancy, Photocell, Vacancy, Gray, 2,400 sq ft, Fluorescent, Incandescent, LED OSSMD-GAG - main

Wall Mount Sensor, Occupancy, Photocell, Vacancy, Gray, 2,400 sq ft, Fluorescent, Incandescent, LED

  • Mfr # OSSMD-GAG

  • Zoro # G210832115

product price: $175.99
/ea
Free Shipping & Returns

Key Features

Sensing Technology
Passive Infrared (PIR)/Ultrasonic
Standards
ASHRAE 90.1, CSA, ETL/cETL, FCC, IECC, Title 24
Color
Gray
Lighting Technology
Fluorescent, Incandescent, LED
Rated Frequency
50/60 Hz
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
OSSMD-GAG
Zoro #
G210832115
UPC #
078477509104
Country of Origin
United States

Dimensions

Overall Depth
1.83 in
Overall Height
4.06 in
Overall Width
1.75 in

Details

Sensing Technology
Passive Infrared (PIR)/Ultrasonic
Standards
ASHRAE 90.1, CSA, ETL/cETL, FCC, IECC, Title 24
Color
Gray
Lighting Technology
Fluorescent, Incandescent, LED
Item
Occupancy Sensor
Rated Frequency
50/60 Hz
Maximum Time Delay
30 min
Includes Motion Sensor
Yes
Load Rating @ 120V AC
10A, LED, 800W, Incandescent, 1,200VA, Fluorescent
Installation Location
Wall Mount
Series
Decora
Horsepower Rating
1/4 hp
Nightlight
No
Coverage Type
Small Motion
Fan Rated
Yes
Number of Gangs
1
Time Delay Adjustment Method
Adaptive
Neutral Required
No
Coverage Angle
180 Degrees
Minimum Time Delay
30 sec
Manufacturer Warranty
5 yr Limited
Minimum Operating Temperature
32 Degrees F
Load Rating @ 277V AC
1,200VA (Fluorescent), 10A (LED), 2,700VA (Fluorescent)
Maximum Coverage Area
2,400 sq ft
Maximum Operating Temperature
104 Degrees F
Number of Buttons
2
Sensor Operation
Occupancy, Photocell, Vacancy
Includes Wall Plate
Wall Plate Not Included
Includes Dimming Switch
Dimming Switch Not Included
Illuminated
Yes
Operating Voltage
120/230/277V AC

Description

Occupancy Sensor, Number of Buttons 2, Sensor Operation Occupancy, Photocell, Vacancy, Lighting Technology Fluorescent, Incandescent, LED, Operating Voltage 120/230/277V AC, Sensing Technology Passive Infrared (PIR)/Ultrasonic, Load Rating @ 120V AC 10A (LED), 800W (Incandescent), 1,200VA (Fluorescent), Maximum Coverage Area 2,400 sq ft, Neutral Required No, Color Gray, Nightlight No, Dimming Method No Dimming, Dimming Type No Dimming, Includes Dimming Switch Dimming Switch Not Included
