  13. Wall Swtch, 3-Way, Side, 120/277V, 20A, Ivory
Leviton Wall Swtch, 3-Way, Side, 120/277V, 20A, Ivory CS320-2I - main

Wall Swtch, 3-Way, Side, 120/277V, 20A, Ivory

  • Mfr # CS320-2I

  • Zoro # G4060087

product price: $5.69
/ea
Sold in multiples of 2 for $11.38

Key Features

Switch Function
Maintained
Body Material
Thermoplastic
Connection
Side Wired
Color
Ivory
Mounting
Box
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CS320-2I
Zoro #
G4060087
UPC #
78477815816
Country of Origin
United States

Dimensions

Height
10.5000 in
Length
17.2500 in
Size
46 H x 1.31 W x 0.92 D in

Details

Switch Function
Maintained
Body Material
Thermoplastic
Connection
Side Wired
Item
Wall Switch
Color
Ivory
Mounting
Box
Voltage
120/277 VAC
Switch Type
3-Way
Standards
NEMA: WD-1 and WD-6ANSI: C-73UL Fed Spec WS896E: File #E7458UL Standard: UL 20CSA C22.2 No. 111: File #152105NOM: 057
Rated HP
1
Switch Style
Toggle
Wiring Method
Side
Amps AC
20
Voltage AC
120 to 277
Locking
No
Antimicrobial
No
Application Environment
Commercial
Description/Special Features
Quiet Switch
Terminal ID
Brass-Hot, Green-Ground, Silver-Neutral
HP Rating
1HP-120V 2HP-240V
Toggle
Polycarbonate
Contacts
Silver-Cadmium .031 Thick
Max. Amperage
16 Amp
ANSI
C-73
Screw Terminal Torque
14-18 in-lbs
Function
3-Way
Dielectric Voltage
Withstands 1500V for 1 minute
Device Type
Toggle Switch
Terminal Accom.
14-12 AWG
Base Material
PBT
Cover Material
Nylon
UL Standard
UL 20
Temperature Rise
Maximum 30 degrees C rise
UL Fed Spec WS896E
File #E7458
Flammability
Rated V-2 per UL94
Terminal Screws
Steel 8-32
Strap Material
Steel
Actuator Material
Polycarbonate
Amperage
20 A
CSA C22.2 No. 111
File #152105
Grade
Commercial Specification Grade
NEMA
WD-1 & WD-6
Operating Temperature
-40°C to 65°C
Termination
Side Wire
Standard
NEMA (WD-1 and WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 111 (File 152105);UL Fed Spec WS-896E (File E7458);UL Standard (UL 20)
Environmental Conditions
Flammability (Rated V-2 per UL94)
Number of Poles
1

Description

20-Amp, 120/277-Volt, Toggle 3-Way AC Quiet Switch, Commercial Grade, Grounding, Ivory
