  11. Pump Motor, 10A Full Load, 14" Shaft L
Little Giant Pump Pump Motor, 10A Full Load, 14" Shaft L 2243009203GS - main

Pump Motor, 10A Full Load, 14" Shaft L

  • Mfr # 2243009203GS

  • Zoro # G607844707

product price: $763.99
/ea
Free Shipping & Returns

Key Features

Phase
Single
HP
1 1/2
Voltage
230V AC
Number of Wires
3
RPM Range
1,725-3,450
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
2243009203GS
Zoro #
G607844707
UPC #
-
Country of Origin
Mexico

Dimensions

Lead Length
4 ft
Height
16 5/8 in
Shaft Length
14 in
Length Less Shaft
15 1/8 in
Shaft Dia.
5/8 in
Body Dia.
3.8 in
Overall Length
13 11/16 in
Manufacturers Warranty Length
1 yr
Bolt Circle Dia.
2 7/8 in

Details

Item
Submersible Pump Motor
Phase
Single
HP
1 1/2
Voltage
230V AC
Number of Wires
3
RPM Range
1,725-3,450
Motor Service Factor
1.15
Motor Bearings
Kingsbury
Nameplate RPM
3,450
Overload Relay Amp Setting
6.6 A
Thrust Rating
650 lb
Motor Shaft Rotation
CCW
Overload Relay Max. Amp Setting
8 A
Motor Application
Pumps
Motor Enclosure Design
Hermetically Sealed
Starter Required
No
Standards
ANSI/NSF 61
Max. Ambient Temp.
86 Degrees F
Full Load Amps
10.0
Stator Type
Hermetically Sealed
Diaphragm Type
Pressure Equalizing
Hz
60 Hz
Overload Relay Required
No
Max. SF Amps
11.5
Motor Sub Application
Water Wells
Motor Thermal Protection
Built-In Lightning Arrestor
Shaft Material
Nitrile Rubber
Motor Design
Capacitor-Start/Run
Motor Shaft Design
Splined
Motor Mounting Type
NEMA Pump Mounting
Nominal Efficiency
73 %
Duty Cycle
Continuous
Motor Frame Material
Stainless Steel
Weight
28 lb
Motor Mounting Position
Vertical Shaft Up
Ins. Class
B
Part Winding Start Capable
No
Inverter Rated
No

Description

Submersible Pump Motor, Bearing Protection Not Applicable, Body Dia. 3.8 in, Bolt Circle Dia. 2 7/8 in, CC Number Not Applicable, Conduit Box Location Not Applicable, Conduit Box Position Not Applicable, Diaphragm Type Pressure Equalizing, Duty Cycle Continuous, Finish Not Applicable, Frame Not Applicable, Hz 60 Hz, Full Load Amps 10.0, Height 16 5/8 in, HP 1 1/2, Includes Not Applicable, Ins. Class B, Inverter Rated No, Inverter Rating Not Applicable, Lead Length 4 ft
