  13. Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 12V DC, DPDT
Macromatic Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 12V DC, DPDT TR-51626-10 - main

Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 12V DC, DPDT

  • Mfr # TR-51626-10

  • Zoro # G8590355

product price: $44.15
/ea

Key Features

Delay Function
Off Delay
Number of Delay Functions
1
Minimum Time Setting
1.8 sec
Maximum Time Setting
3 min
Base Shape
Octal
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TR-51626-10
Zoro #
G8590355
UPC #
801262049116
Country of Origin
United States

Dimensions

Overall Height - Relay
3.1 in
Overall Depth
3.5 in
Body Depth
2.9 in
Body Height
1.7 in
Body Width
2.3 in

Details

Item
Single Function Time Delay Relay
Delay Function
Off Delay
Number of Delay Functions
1
Minimum Time Setting
1.8 sec
Maximum Time Setting
3 min
Base Shape
Octal
Number of Pins
11
Coil Voltage
12V DC
Current Rating
10 A
Contact Form
DPDT
Contact Rating (AC)
10 A @ 240V AC
Contact Rating (DC)
10 A @ 30V
Status Indicator
None
Operating Functions
2
Standards
CE Certified, CSA Certified, UL Listed, UL Socket
Socket Code
A
Socket
1EGP2, 1EGP4, 6X156
Coil Rating
2W
Electrical Connection
Socket
Contact Material
Silver Nickel
Adjustment Method
Potentiometer
Contact Amp Rating (Resistive)
10A
Input Voltage
12V DC
Sealing
Enclosed
Frequency
50/60 Hz
Minimum Operating Temperature
-18 Degrees F
Mounting Style
Plug-In
Maximum Operating Temperature
122 Degrees F
Adjustment Interface
Analog
Power Consumption
2 VA
Reset Method
Time-Limit Reset
Mechanical Operating Durability
10,000,000
Operating Time Accuracy
+0% -50% (Minimum Setting (Adjustable)), +2% 50ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
IP Rating
IP20
Electrical Operating Durability
100,000
Maximum Setting (Adjustable)
+5%, -0%;
Voltage Tolerance
AC Operation: +10/-15% of nominal at 50/60 Hz.; DC Operation: +10/-15% of nominal.
Timing Range
1.8 - 180 seconds
Enclosure Style
Plug-in case utilizing industry-standard 8 or 11 pin octal sockets
Fixed
+2% or 100ms, whichever is greater
Timing Adjustment
Analog
Output Contacts
10A @ 240V AC, 8A @ 28V DC, 1/2HP @ 240V AC, 1/4HP @ 120V AC, B300 & R300
Mount
Plug-in
Control Voltage
12V DC
Temperature
-28°to 65°C (-18°to 149°F)
Repeat Accuracy (Constant Voltage & Temperature)
+1% or 50ms, whichever is greater
Reset Time
0.1 Seconds
Load (Burden)
2 VA
Life
Mechanical: 2,000,000 operations; Full Load: 100,000 operations
Minimum Setting (Adjustable)
+0%, -50%.

Description

Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Off Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 1.8 sec, Maximum Time Setting 3 min, Number of Pins 11, Sealing Enclosed, Mounting Style Plug-In
