  13. Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 24V AC/DC, DPDT
Macromatic Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 24V AC/DC, DPDT TR-51628-10 - main

Single Function Time Delay Relay, Octal, Off Delay, 1 Functions 24V AC/DC, DPDT

  • Mfr # TR-51628-10

  • Zoro # G5234476

product price: $43.79
/ea

Key Features

Delay Function
Off Delay
Number of Delay Functions
1
Minimum Time Setting
1.8 sec
Maximum Time Setting
3 min
Base Shape
Octal
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TR-51628-10
Zoro #
G5234476
UPC #
801262049352
Country of Origin
United States

Dimensions

Overall Height - Relay
3.1 in
Body Depth
2.9 in
Body Height
1.7 in
Overall Depth
3.5 in
Body Width
2.3 in

Details

Item
Single Function Time Delay Relay
Delay Function
Off Delay
Number of Delay Functions
1
Minimum Time Setting
1.8 sec
Maximum Time Setting
3 min
Base Shape
Octal
Number of Pins
11
Coil Voltage
24V AC/DC
Current Rating
10 A
Contact Form
DPDT
Contact Rating (AC)
10 A @ 240V AC
Contact Rating (DC)
10 A @ 30V
Status Indicator
None
Electrical Connection
Socket
Coil Rating
2VA
Operating Functions
2
Socket Code
A
Contact Material
Silver Nickel
Adjustment Method
Potentiometer
Standards
CE Certified, CSA Certified, UL Listed, UL Socket
Socket
1EGP2, 1EGP4, 6X156
Contact Amp Rating (Resistive)
10A
Input Voltage
24V AC/DC
Adjustment Interface
Analog
Reset Method
Time-Limit Reset
Mechanical Operating Durability
10,000,000
Maximum Operating Temperature
122 Degrees F
IP Rating
IP20
Mounting Style
Plug-In
Electrical Operating Durability
100,000
Minimum Operating Temperature
-18 Degrees F
Frequency
50/60 Hz
Operating Time Accuracy
+0% -50% (Minimum Setting (Adjustable)), +2% 50ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
Power Consumption
2 VA
Sealing
Enclosed
Control Voltage
24V AC/DC
Timing Adjustment
Analog
Load (Burden)
2 VA
Timing Range
1.8 - 180 seconds
Repeat Accuracy (Constant Voltage & Temperature)
+1% or 50ms, whichever is greater
Temperature
-28°to 65°C (-18°to 149°F)
Voltage Tolerance
AC Operation: +10/-15% of nominal at 50/60 Hz.; DC Operation: +10/-15% of nominal.
Reset Time
0.1 Seconds
Fixed
+2% or 100ms, whichever is greater
Life
Mechanical: 2,000,000 operations; Full Load: 100,000 operations
Mount
Plug-in
Minimum Setting (Adjustable)
+0%, -50%.
Enclosure Style
Plug-in case utilizing industry-standard 8 or 11 pin octal sockets
Maximum Setting (Adjustable)
+5%, -0%;
Output Contacts
10A @ 240V AC, 8A @ 28V DC, 1/2HP @ 240V AC, 1/4HP @ 120V AC, B300 & R300

Description

Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 24V AC/DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Off Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 24V AC/DC, Minimum Time Setting 1.8 sec, Maximum Time Setting 3 min, Number of Pins 11, Sealing Enclosed, Mounting Style Plug-In
