  13. Lifting Magnet, 3000 lb Cap, 19-1/4 In OAL
Shop All Below the Hook Lifting Magnets
Mag-Mate

Lifting Magnet, 3000 lb Cap, 19-1/4 In OAL

product price: $1,800.00
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Max. Rated Flat Capacity 3,000 lb
  • Magnet Activation Non-Marring Roller Cam
  • Overall Height 7 in
  • Magnet Length 15 1/4 in
  • Overall Length 19 1/4 in
See all product information

Product Information

Dimensions

Overall Height 7 in
Magnet Length 15 1/4 in
Overall Length 19 1/4 in
Magnet Width 9 3/4 in
Handle Length 16 in
Bail Opening Width 3 in
Magnet Height 2 1/2 in
Overall Width 10 1/2 in
Bail Opening Height 2 7/8 in
Bail Inside Width 3 in
Bail Inside Length 2 7/8 in

Details

Item Lifting Magnet
Max. Rated Flat Capacity 3,000 lb
Magnet Activation Non-Marring Roller Cam
Footnotes Max. Rated Capacities Based On Clean, Polished Steel and Dependant on Material Thickness and Size
Max. Rated Capacity @ Min. Activation Thickness 800 lb
Required Material Thickness for Max Rated Capacity 3 in
Max. Heat Resistant Temp. 300 Degrees F
Standards ASME B30.20
Features Jack Screw Secondary Release, Stainless Steel Casing, Minimal Torque Required to Release Load, Lift Capacity Stated On Magnet, Spring Return Handle
Magnet Material Ceramic
Min. Material Thickness for Activation 3/16 in
Includes Non Marring Roller Cam
Minimum Operating Temperature -148 Degrees F
Maximum Flat Load Capacity 3,000 lb
Maximum Operating Temperature 300 Degrees F
Activation Mechanism Pry-Off Handle with Nonmarring Roller
Minimum Thickness for Maximum Load Capacity 3 in
Maximum Load Capacity 3,000 lb
Minimum Thickness for Activation 3/16 in
Number of Poles 17
Bail Thickness 3/8 in

Description

Lifting Magnet, Maximum Flat Load Capacity 3,000 lb, Maximum Round Load Capacity Not Applicable, Minimum Thickness for Activation 3/16 in, Minimum Thickness for Maximum Load Capacity 3 in, Activation Mechanism Pry-Off Handle with Nonmarring Roller, Magnet Length 15 1/4 in, Magnet Width 9 3/4 in, Magnet Height 2 1/2 in, Overall Length 19 1/4 in, Overall Width 10 1/2 in, Overall Height 7 in, Bail Inside Width 3 in, Bail Inside Length 2 7/8 in, Handle Length 16 in
