  13. Lifting Magnet, 400 lb Cap, 7-3/4 In OAL
Shop All Below the Hook Lifting Magnets
Mag-Mate

Lifting Magnet, 400 lb Cap, 7-3/4 In OAL

product price: $485.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Max. Rated Flat Capacity 400 lb
  • Overall Height 6 3/4 in
  • Magnet Activation Non-Marring Roller Cam
  • Magnet Length 4 in
  • Overall Length 7 3/4 in
See all product information

Product Information

Dimensions

Overall Height 6 3/4 in
Magnet Length 4 in
Overall Length 7 3/4 in
Magnet Width 6 1/2 in
Handle Length 16 in
Magnet Height 2 1/2 in
Bail Opening Height 2 7/8 in
Bail Opening Width 3 in
Overall Width 7 1/4 in
Bail Inside Length 2 7/8 in
Bail Inside Width 3 in

Details

Item Lifting Magnet
Max. Rated Flat Capacity 400 lb
Magnet Activation Non-Marring Roller Cam
Magnet Material Ceramic
Footnotes Max. Rated Capacities Based On Clean, Polished Steel and Dependant on Material Thickness and Size
Standards ASME B30.20
Features Jack Screw Secondary Release, Stainless Steel Casing, Spring Return Handle
Required Material Thickness for Max Rated Capacity 3 in
Max. Rated Capacity @ Min. Activation Thickness 400 lb
Min. Material Thickness for Activation 3/16 in
Max. Heat Resistant Temp. 300 Degrees F
Includes Non Marring Roller Cam
Minimum Thickness for Activation 3/16 in
Number of Poles 4
Minimum Thickness for Maximum Load Capacity 3 in
Maximum Flat Load Capacity 400 lb
Maximum Operating Temperature 300 Degrees F
Minimum Operating Temperature -148 Degrees F
Activation Mechanism Pry-Off Handle with Nonmarring Roller
Maximum Load Capacity 400 lb
Bail Thickness 3/8 in

Description

Lifting Magnet, Maximum Flat Load Capacity 400 lb, Maximum Round Load Capacity Not Applicable, Minimum Thickness for Activation 3/16 in, Minimum Thickness for Maximum Load Capacity 3 in, Activation Mechanism Pry-Off Handle with Nonmarring Roller, Magnet Length 4 in, Magnet Width 6 1/2 in, Magnet Height 2 1/2 in, Overall Length 7 3/4 in, Overall Width 7 1/4 in, Overall Height 6 3/4 in, Bail Inside Width 3 in, Bail Inside Length 2 7/8 in, Handle Length 16 in

Restrictions

  • Hazardous material
